Panasonic EEFCS1V100R Conductive Polymer Capacitor
The EEFCS1V100R is a high-performance conductive polymer aluminum electrolytic capacitor designed for electronic applications requiring reliable power filtering and stabilization. It features a rated voltage of 10V, a capacitance of 100μF, and a dimensions of 73 x 43 x 14 mm. The capacitor is RoHS compliant and halogen-free, suitable for surface mount technology with high ripple current capacity of up to 3200mA. Its robust design ensures durability under high temperatures and ripple conditions, making it ideal for consumer electronics, industrial equipment, and power supply circuits.
Panasonic EEFCS1V100R Conductive Polymer Capacitor Specifications:
- Series: EEFCS1V
- Voltage Range: 10V to 35V
- Capacitance: 100μF
- Dimensions: 73 x 43 x 14 mm
- Ripple Current: 3200mA at 100kHz / +45 °C
- Leakage Current: Max 0.3 CV(μA) at 2 min
- Temperature Range: -55°C to +105°C
- RoHS compliant and Halogen free
- Dissipation factor (tan δ): Max 0.06 at 120Hz / +20°C
- Surge Voltage: 1.15 x rated voltage
- Endurance: 2000 hours at 105°C with rated voltage
- Polarity: Positive terminal marked
- Mounting: Surface mount, auto-placement compatible
- Reflow soldering: IR / Hot-air, vapour phase reflow for compatible series
- Storage: -55°C to +105°C, up to 2 years in unopened packaging
Buy the Panasonic EEFCS1V – Reliable Conductive Polymer for Industrial Applications
Enhance your electronic projects with the Panasonic Conductive Polymer Capacitor series. Featuring high ripple current capability, compact size, and RoHS compliance, these surface mount capacitors ensure reliable power filtering in industrial and consumer electronics. Designed for high-temperature endurance and low equivalent series resistance, they provide excellent performance under demanding conditions. Suitable for power supply circuits, motor drives, and various high-reliability applications, they are available for online purchase, guaranteeing fast delivery and authentic Panasonic quality for your critical electronic designs.
Order your Panasonic Series EEFCS1V 10V 100μF surface mount capacitor today and ensure your power circuits are protected with dependable quality.
Frequently Asked Questions
Where can I buy Panasonic EEFCS1V100R?
You can click on the BUY or RFQ button to purchase EEFCS1V100R from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEFCS1V100R?
You can download the EEFCS1V100R datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEFCS1V100R?
Panasonic
