Panasonic EEHZT1J560P Conductive Polymer Capacitor
The Conductive Polymer Hybrid Aluminum Electrolytic Capacitors of the ZT series are surface-mount type components designed for high-temperature, high-reliability applications. These capacitors incorporate conductive polymer technology to deliver superior ripple current capabilities, enduring 4000 hours at 125°C. They are compliant with AEC-Q200 and RoHS standards, featuring a rated voltage range of 25V to 63V and capacitance values from 33μF to 220μF. Ideal for automotive, industrial, and consumer electronics, these capacitors provide excellent stability, vibration resistance, and low ESR for demanding circuits, ensuring long-lasting performance in harsh environments.
Panasonic EEHZT1J560P Conductive Polymer Capacitor Specifications:
- Series: ZT series
- Type: Surface Mount
- Temperature Range: -55°C to +125°C
- Rated Voltage: 25V to 63V
- Capacitance: 33μF to 220μF
- Capacitance Tolerance: ±20 %
- Endurance: 4000 hours at 125°C
- Ripple Current: 75 % to 118 % higher than ZC series
- Dissipation Factor (tan δ): ≤200 % of initial limit
- ESR (Equivalent Series Resistance): ≤200 % of initial limit
- Leakage Current: within initial limit, at specified conditions
- RoHS and AEC-Q200 compliant
- Support for vibration-proof applications upon request
- Dimensions: varies by capacitance and size code
- Support terminals extended for pressure relief and mounting
- Certification: RoHS compliant, capable of high-temperature reflow process
- Design: Hybrid polymer electrolytic technology for increased reliability
Buy the Panasonic Series ZT Conductive Polymer Hybrid Aluminum Capacitors: EEHZT1J560P
Experience the superior performance of Panasonic Conductive Polymer Hybrid Aluminum Capacitors. Designed for demanding environments, these surface-mount capacitors feature high ripple current capacity, endurance at 125°C for 4000 hours, and compliance with RoHS and AEC-Q200 standards. Ideal for automotive, industrial, and consumer applications, they deliver excellent stability, low ESR, and vibration resistance. Purchase online today to ensure reliable operation, enhanced circuit stability, and long-term durability, backed by Panasonic’s trusted quality and technical support.
Get Panasonic ZT series EEHZT1J560P today—built for high ripple current and long-lasting durability at elevated temperatures.
Frequently Asked Questions
Where can I buy Panasonic EEHZT1J560P?
You can click on the BUY or RFQ button to purchase EEHZT1J560P from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEHZT1J560P?
You can download the EEHZT1J560P datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEHZT1J560P?
Panasonic
