Panasonic EEUED2D101S Aluminum Electrolytic Capacitor
The EEUED2D101S is a high-reliability aluminum electrolytic capacitor designed for general-purpose electronic circuits. It features a 100 V rated voltage, 10 µF capacitance, and an endurance of 10,000 hours at 105°C with low ESR and ripple current capabilities suitable for power supplies and voltage smoothing applications. Its radial lead design allows easy mounting on PCB, with a maximum height of approximately 20 mm. Constructed with a durable aluminum case and insulated sleeve, it ensures stable performance in demanding environments, meeting RoHS compliance and safety standards for reliable use in various industrial and consumer electronics.
Panasonic EEUED2D101S Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 10 µF
- Rated Voltage: 100 V
- Endurance: 10,000 hours at 105°C
- Temperature Range: -25°C to +105°C
- Leakage Current: within initial limit after 1000 hours at 105°C
- Capacitance Tolerance: +20% at 120 Hz / +20°C
- Impedance Ratio at 120 Hz: Z(-25°C) / Z(+20°C) = 3
- Maximum Height: approximately 20 mm
- Lead Length: 20 mm (minimum)
- Terminal Diameter: 0.6 mm
- Material: Aluminum case with insulating sleeve
- Compliance: RoHS
- Application: Power supplies, voltage smoothing, electronic circuits requiring reliable electrolytic capacitance
- Packaging: Tape and reel for automated insertion
- Shelf Life: 12 months stored at recommended conditions
Buy the Panasonic Series ED-A Aluminum Electrolytic Capacitors: EEUED2D101S
Get the Panasonic Series ED-A EEUED2D101S aluminum electrolytic capacitor online today to ensure your electronic projects benefit from high reliability, long endurance of 10,000 hours at 105°C, and stable performance for power supply and filtering applications. This compact, RoHS-compliant capacitor features a 10 µF capacitance, 100 V rated voltage, and fuel-efficient design with radial lead configuration for easy PCB mounting. Perfect for demanding industrial electronics and consumer devices, order now for fast delivery and quality assurance.
Order your Panasonic Series ED-A EEUED2D101S today and upgrade your power circuits with our reliable high-capacity electrolytic capacitors.
Frequently Asked Questions
Where can I buy Panasonic EEUED2D101S?
You can click on the BUY or RFQ button to purchase EEUED2D101S from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUED2D101S?
You can download the EEUED2D101S datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUED2D101S?
Panasonic
