Panasonic EEUFM1E102B Aluminum Electrolytic Capacitor
Panasonic's EEU-FM1E102B aluminum electrolytic capacitor is a robust component designed for reliability in various industrial applications. It boasts a 105°C endurance rating, ensuring long-term performance under demanding conditions. The capacitor's low impedance characteristics contribute to efficient power delivery and reduced energy loss. RoHS compliance further enhances its suitability for environmentally conscious designs. This capacitor is ideal for power supplies, filtering circuits, and other applications requiring stable capacitance and high reliability.
Panasonic EEUFM1E102B Aluminum Electrolytic Capacitor Specifications:
- Endurance: 105 ℃ 2000 h to 7000 h
- Low impedance: 40 % to 70 % less than FC series
- Rated voltage range: 6.3 V to 50 V
- Capacitance range: 22μF to 6800μF
- Capacitance tolerance: ±20 %(120 Hz/+20℃)
- Leakage current: I ≦ 0.01 CV(μA)After 2 minutes
- Dissipation factor (tan δ): 0.22 to 0.10
- Endurance Duration: φ5 to φ6.3 : 2000 h, φ8×11.5 to φ8×15: 3000 h, φ8×20 to φ10×16 : 4000 h, φ10×20 to φ12.5×20/ φ16×20 : 5000 h, φ12.5×25 toφ12.5×35/ φ16×25 : 7000 h
- Capacitance change: Within ±25 % of the initial value (6.3 V to 10 V : ±30 %)
- DC leakage current: Within the initial limit
- Shelf life: Stabilized at +20 °C, capacitors shall meet the limits specified in endurance.
- Frequency correction factor for ripple current: See table
- Dimensions: See table
- Rated voltage: 6.3 to 35 V
- Impedance: See table
- Ripple current: See table
Buy the EEU-FM1E102B PANASONIC Aluminum Electrolytic Capacitor | myMectronic
Purchase the Panasonic EEU-FM1E102B aluminum electrolytic capacitor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic EEUFM1E102B?
You can click on the BUY or RFQ button to purchase EEUFM1E102B from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUFM1E102B?
You can download the EEUFM1E102B datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUFM1E102B?
Panasonic
