Panasonic EEUFP1V511B Aluminum Electrolytic Capacitor
High-quality aluminum electrolytic capacitors designed for reliable performance in electronic circuits. Featuring radial leads, these capacitors offer high ripple current capacity, large capacitance, and are compliant with AEC-Q200 and RoHS standards. Rated for temperatures from -55°C to +105°C, with nominal voltages ranging from 25V to 35V, they deliver stable electrical characteristics with low leakage current and excellent endurance. Ideal for power supplies, audio equipment, and industrial applications, these capacitors ensure long-lasting durability and efficient operation in demanding environments.
Panasonic EEUFP1V511B Aluminum Electrolytic Capacitor Specifications:
- Category Temperature Range: -55°C to +105°C
- Rated Voltage Range: 25V to 35V
- Capacitance Range: 510 UF to 2000 UF
- Capacitance Tolerance: ±20% (120Hz/+20°C)
- Endurance: 4000h at 105°C
- Shelf Life: 1000h at 105°C
- Leakage Current: within initial limit
- Dissipation Factor (tan δ): 0.14 at 20°C
- Ripple Current: up to 4000mA rms at 100kHz
- Physical Size: 10x16mm, 12.5x20mm, 12.5x25mm, 10x20mm
- Lead Length: 5.0mm
- Compliance: RoHS, AEC-Q200
- Material: Aluminum oxide dielectric with electrolyte electrolyte
- Terminals: Radial Leads, solderable
- Temperature Coefficient: Low ESR and high ripple capacity
Buy the Buy Panasonic Aluminum Electrolytic Capacitors Part Number EEUFP1V511B Online
Experience reliable performance with Panasonic aluminum electrolytic capacitors available online. Designed with radial leads, these capacitors handle high ripple currents, offer large capacitance values, and operate efficiently over a wide temperature range. Perfect for power supplies, audio equipment, industrial systems, and demanding environments, their robust construction ensures long-term durability and stable electrical performance. Purchase today and enhance your electronic designs with high-quality, RoHS-compliant capacitors that meet industrial standards for safety and reliability.
Get Panasonic EEUFP1V511B today—designed for high ripple current and long-lasting durability in power supply applications.
Frequently Asked Questions
Where can I buy Panasonic EEUFP1V511B?
You can click on the BUY or RFQ button to purchase EEUFP1V511B from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUFP1V511B?
You can download the EEUFP1V511B datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUFP1V511B?
Panasonic
