Panasonic EEUFR1V680B Aluminum Electrolytic Capacitor
The Panasonic FR series capacitors are polarized aluminum electrolytic capacitors with radial leads. They have capacitance values ranging from 4.7 µF to 8200 µF and are designed for applications requiring ultra-low ESR, high ripple current handling, and long lifespan in a compact form factor. These capacitors feature improved material technology over the Panasonic FM series, offering up to a 100% increase in endurance and up to 30% higher capacitance. They operate at voltages from 6.3VDC to 100VDC, with a tolerance of ±20%. The endurance spans from 5,000 to 10,000 hours at 105°C, with an operating temperature range of -40°C to 105°C, ensuring high reliability.
Panasonic EEUFR1V680B Aluminum Electrolytic Capacitor Specifications:
- Capacitance Range: 4.7 µF to 8200 µF
- Rated Voltage: 6.3 VDC to 100 VDC
- Temperature Range: -40°C to +105°C
- Endurance: 5000 h to 10000 h at 105°C
- Capacitance Tolerance: ±20%
- Leakage Current: < 0.01 CV (after 2 minutes)
- Dissipation Factor: tan δ ≤ 0.22 at 120 Hz/+20°C (for selected values)
- RoHS compliant
- Leakage Current: Within initial limit after testing
- Case Size: Various (e.g., 6.3 x 11.2 mm, 8 x 11.5 mm, etc.)
- Impédance: Approx. 0.130Ω to 0.300Ω at 100 kHz and +20°C
- Ripple Current: Up to 3.190 mA rms at 100 kHz
- Lifespan: Up to 10000 hours at 105°C
Buy the Buy Panasonic Aluminum Electrolytic Capacitors Part Number EEUFR1V680B Online
Secure your Panasonic aluminum electrolytic capacitor EEUFR1V680B now through our online store. These radial lead capacitors offer excellent low ESR, high ripple current capacity, and endurance up to 10,000 hours at 105°C. Perfect for high-reliability power supplies, filtering, and decoupling in industrial, consumer, and professional equipment. With a wide voltage range and superior material construction, these capacitors ensure stable operation in demanding environments. Purchase online today for fast shipping, competitive prices, and trusted quality in every component.
Order your Panasonic SeriesEEUFR1V680B high-temperature electrolytic capacitor today and ensure long-lasting, reliable performance for your electronic projects.
Frequently Asked Questions
Where can I buy Panasonic EEUFR1V680B?
You can click on the BUY or RFQ button to purchase EEUFR1V680B from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUFR1V680B?
You can download the EEUFR1V680B datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUFR1V680B?
Panasonic
