Panasonic EEUFS0J272 Aluminum Electrolytic Capacitors
Panasonic aluminum electrolytic capacitors in radial lead configuration offer high endurance at 105°C, low ESR, and miniaturized 1 size smaller than series FR. Suitable for power supply filtering and timing circuits, they provide reliable performance with capacity ranges from 27 UF to 10,000 UF, rated voltages from 6.3 V to 100 V, and long service lifespans up to 10,000 hours. With RoHS compliance and stable operation across a broad temperature range, these capacitors are ideal for demanding electronic applications requiring high stability, low leakage, and high ripple current handling.
Panasonic EEUFS0J272 Aluminum Electrolytic Capacitors Specifications:
- Capacitance Range: 27 UF to 10,000 UF
- Rated Voltage Range: 6.3 V.DC to 100 V.DC
- Temperature Range: -40°C to +105°C
- Endurance: 5,000 to 10,000 hours at 105°C
- Leakage Current: < 0.01 CV (μA) after 2 minutes
- Dissipation Factor (tan δ): 0.22 to 0.08 (120 Hz/+20°C)
- Capacitance Tolerance: ±20%
- RoHS Compliant
- Compliance with safety and reliability standards for electronics manufacturing
- Long shelf life after storage at +105°C for 1,000 hours with no voltage
- High ripple current capacity up to 3750 mA (100 V, 16×20 mm case)
Buy the Buy Panasonic Aluminum Electrolytic Capacitors Part Number EEUFS0J272 Online
Enhance your electronic projects with Panasonic aluminum electrolytic capacitors. Designed for long-lasting performance under demanding conditions, these capacitors provide low ESR, high ripple current, and high reliability from -40°C to +105°C. With a wide capacitance range from 27 UF to 10,000 UF and voltage options up to 100 V, they ensure your power supplies and filtering circuits operate efficiently. RoHS compliant, these high-quality components support sustainable electronics design and are readily available for online purchase to meet your project timelines.
Get Panasonic EEUFS0J272 today—built for high endurance, low ESR, and long-lasting stability in your electronic designs.
