Panasonic EEUFS1A181 Aluminum Electrolytic Capacitor
These Panasonic aluminum electrolytic capacitors feature radial lead type construction, low ESR, and miniaturized design, making them suitable for various industrial applications. They operate within a temperature range of -40°C to +105°C and offer high endurance of up to 10,000 hours at 105°C. With capacities from 27UF to 10,000UF and rated voltages from 6.3V to 100V, these RoHS-compliant capacitors deliver reliable performance with low leakage current and stable impedance, ideal for power supply filtering, smoothing, and decoupling in electronic circuits.
Panasonic EEUFS1A181 Aluminum Electrolytic Capacitor Specifications:
- Operating Temperature Range: -40°C to +105°C
- Capacitance Range: 27 UF to 10,000 UF
- Rated Voltage Range: 6.3 V.DC to 100 V.DC
- Capacitance Tolerance: ±20%
- Leakage Current: < 0.01 CV (μA) after 2 minutes
- Endurance: 105°C for 5,000 to 10,000 hours depending on model
- Dissipation Factor (tan δ): 0.22 to 0.08 (at 120 Hz/+20°C), add 0.02 per 1000 UF for ≥1000 UF
- Impedance (QL) at 100 kHz: 0.300 to 0.012 Ω depending on size
- Case Size: 5x11 mm to 16x25 mm
- Lead Length: 200 mm standard, min. varies by model
- RoHS Compliant: Yes
- Endurance Test Conditions: DC voltage +105°C for up to 10,000 hours
Buy the Panasonic EEFS1A181 – Reliable Aluminum Electrolytic Capacitors for Industrial Applications
Order Panasonic aluminum electrolytic capacitors online today and ensure reliable power management for your electronic projects. Designed for high endurance, low ESR, and stable performance across a wide temperature range, these capacitors are ideal for industrial, power supply, and electronic circuit applications. With capacities from 27UF to 10,000UF and rated voltages up to 100V, they provide low leakage current and excellent ripple handling. Trust Panasonic for quality components that deliver durability and consistent performance long-term.
Get Panasonic aluminum electrolytic capacitors today—built for precision and long-lasting durability in power supply filtering and smoothing.
Frequently Asked Questions
Where can I buy Panasonic EEUFS1A181?
You can click on the BUY or RFQ button to purchase EEUFS1A181 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUFS1A181?
You can download the EEUFS1A181 datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUFS1A181?
Panasonic
