Panasonic EEUTP1E471B Electrolytic Capacitor
The Panasonic EEU-TP1E471B is a radial lead type aluminum electrolytic capacitor, part of the TP series. It's characterized by its endurance of 125°C, making it suitable for demanding applications. The capacitor offers a smaller size compared to the TA series and boasts a higher ripple current capability, up to 40% greater than the TA series. It is RoHS compliant and AEC-Q200 compliant, ensuring adherence to industry standards. This capacitor finds use in power supplies, filtering circuits, and other applications requiring stable capacitance and high ripple current handling.
Panasonic EEUTP1E471B Electrolytic Capacitor Specifications:
- Endurance: 125 °C 2000 h to 5000 h or 135 °C 1000 h to 2000 h
- Category temperature range: –40 °C to + 135 °C
- Rated voltage range: 25 V .DC to 35 V .DC
- Capacitance range: 100 µF to 5100 µF
- Capacitance tolerance: ±20 % (120 Hz/+20 °C)
- Leakage current: I<0.01CV After 2 minutes
- Dissipation factor (tand): 0.14 to 0.12
- Capacitance change (Endurance 1): Within ±30 % of the initial value
- DC leakage current (Endurance 1): Within the initial limit
- Capacitance change (Endurance 2): Within ±30 % of the initial value
- DC leakage current (Endurance 2): Within the initial limit
- Shelf Life 1: Meets Endurance limits after storage at +125 °C
- Shelf Life 2: Meets Endurance limits after storage at +135 °C
- AEC-Q200: Compliant
- Frequency correction factor for ripple current (25-35V, 330µF): 0.85 at 1 kHz
- Dimensions: L (100 kHz) (100 kHz) (120 Hz) (Ω) (+20 °C) (+20 °C) (hours) (hours) Lead dia. 0d Lead space
- Case size (mm): 0D 8 10 12.5 16 18
- Lead length (mm): 5.0
- Lead space: 5.0
