Panasonic EEUTP1V101B Electrolytic Capacitor Radial
Panasonic's EEU-TP1V101B is a robust aluminum electrolytic capacitor designed for radial lead applications. It offers a combination of high ripple current capability, a compact form factor, and endurance, making it suitable for various industrial and automotive applications. The capacitor's AEC-Q200 compliance ensures reliability in demanding environments. Its smaller size compared to the TA series provides design flexibility, while its high ripple current performance enhances efficiency in power circuits.
Panasonic EEUTP1V101B Electrolytic Capacitor Radial Specifications:
- Endurance: 125 °C 2000 h to 5000 h or 135 °C 1000 h to 2000 h
- Category temperature range: –40 °C to + 135 °C
- Rated voltage range: 25 V .DC to 35 V .DC
- Capacitance range: 100 µF to 5100 µF
- Capacitance tolerance: ±20 % (120 Hz/+20 °C)
- Leakage current: I<0.01CV After 2 minutes
- Dissipation factor (tand): 0.14 to 0.12
- Capacitance change: Within ±30 % of the initial value
- DC leakage current: Within the initial limit
- Shelf Life 1: After storage for 1000 hours at +125 °C±2 °C
- Shelf Life 2: After storage for 1000 hours at +135 °C±2 °C
- AEC-Q200: AEC-Q200 compliant
Buy the EEU-TP1V101B PANASONIC Electrolytic Capacitor Radial | myMectronic
Purchase the Panasonic EEU-TP1V101B Electrolytic Capacitor Radial with confidence and security.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic EEUTP1V101B?
You can click on the BUY or RFQ button to purchase EEUTP1V101B from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part EEUTP1V101B?
You can download the EEUTP1V101B datasheet or visit the Panasonic website for support.
Who is the manufacturer of EEUTP1V101B?
Panasonic
