Panasonic EEVFK2A331M Aluminum Electrolytic Capacitor
Panasonic's EEV-FK2A331M series capacitors are surface mount devices designed for a wide range of industrial applications. These capacitors offer enhanced endurance up to 105°C and exhibit low impedance characteristics, improving circuit efficiency. A vibration-proof option is available for applications requiring increased reliability in harsh environments. They are AEC-Q200 compliant and RoHS compliant, making them suitable for automotive and other sensitive applications. The capacitor's compact size and robust performance make it a versatile choice for power supplies, filtering, and decoupling circuits.
Panasonic EEVFK2A331M Aluminum Electrolytic Capacitor Specifications:
- Endurance: 105 °C 2000 h to 5000 h
- Low impedance: 40 % to 60 % less than FC series
- Miniaturized: 30 % to 50 % less than FC series
- Vibration-proof: 30G guaranteed (ø6.3 ≦)
- AEC-Q200 compliant: Yes
- RoHS compliant: Yes
- Temperature range: –55 °C to +105 °C
- Rated voltage range: 6.3 V to 100 V
- Capacitance range: 3.3μF to 6800μF
- Capacitance tolerance: ±20 % (120 Hz/+20 °C)
- Leakage current: I ≦ 0.01 CV or 3(μA) After 2 minutes
- Dissipation factor: Please see attached characteristics list
- Correction factor for ripple current: {'50,60 (Hz)': '0.70', '120 (Hz)': '0.75', '1 k (Hz)': '0.90', '10 k (Hz)': '0.95', '100 k to': '1.00'}
