Panasonic ENW89852AXKF Bluetooth Module
The PAN1740A is an advanced Bluetooth 5.0 Low Energy module optimized for embedded applications such as remote control units, health monitoring, and human interaction devices. It features an integrated radio transceiver, baseband processor, and an ARM Cortex-M0 CPU, supporting up to eight simultaneous connections. The module includes Bluetooth LE profiles, cryptography, and interfaces like UART, SPI, and GPIOs. Its small form factor (9mm x 9.5mm x 1.8mm), low power consumption, and on-chip antenna make it ideal for compact, battery-powered systems requiring reliable wireless connectivity and voice/motion recognition capabilities.
Panasonic ENW89852AXKF Bluetooth Module Specifications:
- Dimensions: 9mm x 9.5mm x 1.8mm in SMD package
- Supports Bluetooth 5.0 LE with up to 8 simultaneous connections
- Integrated ARM Cortex-M0 CPU, 32-bit RISC architecture
- Memory: 128kB ROM, 64kB OTP, 96kB SRAM
- Operating temperature: -40°C to +85°C
- Low power modes with sleep currents as low as 1.9 pA
- CRystal oscillator: 16 MHz and 32.768 kHz with startup times of 0.5-3 ms and 0.4 sec respectively
- Interfaces: UART, SPI, GPIO, JTAG, ADC, Timers, Reset
- Peak power consumption: 4.9 mA in Rx/Tx
- Supported profiles: GATT, GAP, custom profiles, Bluetooth SIG profiles
- Supports AES-128 encryption, hardware link layer
- Antenna: Integrated chip antenna, interface directly with antenna
- Power supply: 3.3V, supply voltage range 2.2 V to 3.6 V
- Features robust EMI shielding and integrated RF front-end
Buy the Panasonic PAN1740A – Reliable Bluetooth 5.0 Module for Industrial Applications
Discover the Panasonic Bluetooth Module, a compact and reliable Bluetooth 5.0 Low Energy device ideal for industrial, automation, and remote control applications. Featuring an integrated ARM Cortex-M0 CPU, high-speed radio transceiver, and support for multiple BLE connections, it offers excellent performance in a small form factor of 9mm by 9.5mm. With low power consumption, robust interfaces such as UART, SPI, GPIOs, and comprehensive Bluetooth profiles, this module ensures seamless integration into your embedded systems. Order online today to enhance your wireless solutions with dependable, high-performance connectivity.
Get Panasonic PAN1740A today—built for reliable wireless connectivity and voice/motion recognition in industrial systems.
Frequently Asked Questions
Where can I buy Panasonic ENW89852AXKF?
You can click on the BUY or RFQ button to purchase ENW89852AXKF from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ENW89852AXKF?
You can download the ENW89852AXKF datasheet or visit the Panasonic website for support.
Who is the manufacturer of ENW89852AXKF?
Panasonic
