Panasonic ERA6AEB4991V Metal Film Chip Resistor
Panasonic's ERA-6AEB4991V metal film chip resistor is engineered for exceptional performance and reliability in a wide range of electronic circuits. Its high accuracy and low resistance tolerance ensure precise circuit operation, while its excellent linearity minimizes signal distortion. The resistor's stability at high temperatures and humidity, combined with its compliance with industry standards like IEC 60115-8 and AEC-Q200, makes it suitable for automotive, industrial, and consumer electronics applications. It's a robust and dependable component for critical circuit designs.
Panasonic ERA6AEB4991V Metal Film Chip Resistor Specifications:
- series: ERA 1A, 2A, 3A, 6A, 8A
- features: ['High reliability: Stable at high temperature and humidity (85 °C 85 %RH rated load, Category temperature range : –55 °C to +155 °C)', 'High accuracy: Low resistance tolerance and Temperature Coefficient of Resistance', 'High performance: Low current noise, excellent linearity', 'Reference Standard: IEC 60115-8, JIS C 5201-8, JEITA RC-2133C', 'AEC-Q200 compliant (except ERA1A)', 'RoHS compliant']
- resistance_range: 100 to 10 kΩ (E24,E96)
- temperature_range: –55 °C to +155 °C
- resistance_tolerance: ±0.1 %
- temp_coeff: ±10×10-6/K
- power_rating: 0.125 W
- limiting_voltage: 100 V
- overload_voltage: 200 V
Buy the ERA-6AEB4991V PANASONIC Metal Film Chip Resistor | myMectronic
Purchase the Panasonic ERA-6AEB4991V Metal Film Chip Resistor securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy Panasonic ERA6AEB4991V?
You can click on the BUY or RFQ button to purchase ERA6AEB4991V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERA6AEB4991V?
You can download the ERA6AEB4991V datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERA6AEB4991V?
Panasonic
