Panasonic ERJB1BF3R0U High Power Chip Resistor
The ERJB1BF3R0U is a high power chip resistor with wide terminal type designed for high reliability in industrial applications. It features excellent heat dissipation and solder-joint reliability, making it suitable for automotive circuits including ECUs, anti-lock braking, and airbag systems. This resistor series complies with AEC-Q200 standards and RoHS directives, ensuring durability under demanding conditions. Its robust construction provides stable performance during overloads and thermal cycling, ideal for current sensing in power supply circuits or high-temperature environments. It combines compact size with high-performance features for critical electronics designs.
Panasonic ERJB1BF3R0U High Power Chip Resistor Specifications:
- Package Type: Wide terminal
- Resistance Range: 10mΩ to 10kΩ
- Resistance Tolerance: ±1%, ±2%, ±5%
- Power Rating: 1W to 2W (varies by series)
- Maximum Operating Voltage: 70V to 125V (depending on resistance)
- Temperature Coefficient: ±100 ppm/°C
- Operating Temperature Range: -55°C to +125°C
- Overload Voltage: Rated voltage x 2.0 to 2.5, 5 seconds
- Thermal Resistance: Good heat dissipation due to wide terminal design
- Compliance: AEC-Q200, RoHS
- Dimensions: Approximate length 5.0 mm, width 0.30 mm, height 0.25 mm (specific to series)
- Material: Metal glaze, nickel-plated terminal
- Mounting Type: Surface-mount device (SMD)
Buy the Panasonic ERJB1BF3R0U – Reliable High Power Chip Resistors for Industrial Applications
Order the Panasonic ERJB1BF3R0U high power chip resistor online today and enhance your electronic designs with its superior heat dissipation, high current handling, and reliability standards. Perfect for automotive ECUs, sensors, and power circuits, this resistor series ensures stable operation under thermal and electrical stress. Its wide terminal construction offers excellent solder-joint reliability, making assembly straightforward and durable. Trust Panasonic's quality, comply with industry standards, and optimize your manufacturing process by purchasing this robust resistor online now for optimal performance and long-term durability.
Buy Panasonic ERJB1BF3R0U high power chip resistor now and experience unmatched reliability and performance in your automotive and industrial circuits.
Frequently Asked Questions
Where can I buy Panasonic ERJB1BF3R0U?
You can click on the BUY or RFQ button to purchase ERJB1BF3R0U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERJB1BF3R0U?
You can download the ERJB1BF3R0U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERJB1BF3R0U?
Panasonic
