Panasonic ERJB1BFR56U High Power Chip Resistor
High power chip resistor with wide terminal construction designed for excellent heat dissipation and reliable solder joints. Suitable for automotive circuits, power supply current sensing, and other high-reliability applications. Compliant with AEC-Q200 and RoHS standards, it features embossed carrier taping for easy surface mounting, with a robust construction that ensures durability in demanding environments.
Panasonic ERJB1BFR56U High Power Chip Resistor Specifications:
- Resistance Range: 10mΩ to 10kΩ
- Power Rating: 1W (at ambient temperature), derated according to temperature curve
- Temperature Range: -55°C to +125°C
- Voltage Rating: 70V to 200V depending on resistance
- Resistance Tolerance: ±1%, ±2%, ±5% (depending on series)
- Construction: Thick film resistor on alumina substrate with wide terminal construction
- Package: Embossed carrier taping, 4mm pitch, 5000 pcs per reel
- Standards: AEC-Q200, RoHS compliant
- Dimensions: Length approx. 2.5mm, Width approx. 5.0mm, Height approx. 0.9mm
- Soldering: Compatible with reflow soldering, with specified temperature profiles
- Certifications: UL Listed, CSA Certified
Buy the Panasonic Series High Power Chip Resistor: ERJB1B
Order Panasonic high power chip resistor ERJB1B online today for high reliability and durability. Perfect for automotive circuits, power sensing, and demanding environments. Features wide terminal construction for excellent heat dissipation and solder joint reliability. RoHS and AEC-Q200 compliant, ensuring safety and quality. Easy to mount on surface boards using embossed carrier taping. Designed with a thick film resistor on alumina substrate, offering consistent performance across a broad temperature range. Enhance your electronic systems with this robust, dependable resistor that ensures accuracy and longevity.
Get Panasonic ERJB1B high power chip resistor today—built for precision and long-lasting durability in automotive and industrial applications.
Frequently Asked Questions
Where can I buy Panasonic ERJB1BFR56U?
You can click on the BUY or RFQ button to purchase ERJB1BFR56U from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERJB1BFR56U?
You can download the ERJB1BFR56U datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERJB1BFR56U?
Panasonic
