Panasonic ERZE10A331 Surge Absorber
The product is a high-performance surge absorber designed to protect electronic components from transient overvoltage conditions. Featuring large surge current handling and energy absorption capability in a compact size, it is suitable for applications like transistor, diode, IC, thyristor, and triac protection, as well as surge protection in consumer electronics, communication, measurement, and home appliances. Compliant with standards including UL1449, VDE IEC61051, IEC62368-1, and CQC, it ensures reliable surge mitigation for critical electronic systems.
Panasonic ERZE10A331 Surge Absorber Specifications:
- Series: E
- Type: D
- Maximum Voltage: 330V (nominal varistor voltage: 297 to 363V)
- Maximum Allowable Voltage: 270V (DC), 210V (AC rms)
- Peak Current: 545A (8/20 μs)
- Energy Handling Capacity: 545J
- Capacitance: 42pF
- Operating Temperature Range: -40 to 85 °C
- Storage Temperature Range: -40 to 125 °C
- Standards Compliance: UL1449, IEC61051, IEC62368-1, CQC
- Dimensions: D max. 9.0 mm, Tmax. 6.0 mm, L+1.0 mm 2.9 mm
- Lead Type: Straight Leads, Taped
- Rated Power: 340 W (8/20 μs)
Buy the Panasonic ERZE10A331 – Reliable Surge Absorber for Industrial Applications
Order the Panasonic ERZE10A331 online today to ensure your electronic equipment is protected against transient overvoltage events. This high-capacity surge absorber offers excellent energy handling and large surge current capacity in a compact size, ideal for consumer electronics, communication devices, and industrial systems. Its compliance with UL1449, VDE IEC standards, and CQC certification guarantees safety and durability. Protect your investments with a reliable surge mitigation component that ensures continuous operation and safety in demanding environments.
Buy Panasonic ERZE10A331 now and experience unmatched reliability and performance in surge protection for your electronic systems.
Frequently Asked Questions
Where can I buy Panasonic ERZE10A331?
You can click on the BUY or RFQ button to purchase ERZE10A331 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERZE10A331?
You can download the ERZE10A331 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERZE10A331?
Panasonic
