Panasonic ERZV10D680 Surge Absorber Varistor
The ERZV10D680 is a high-performance surge absorber varistor designed for circuit protection in electronic equipment. It features a maximum voltage of 680V and withstands surge currents up to 135A, 8/20μs waveform. Built with ROHS compliance, it offers excellent energy absorption capacity, rated peak current of 3500A, and low capacitance of 8.2pF. Suitable for AC/DC applications, it ensures reliable performance with a maximum allowable voltage of 1120V DC and operates efficiently within -40°C to +85°C. Its compact size and robust construction make it ideal for surge suppression in communication and consumer electronics.
Panasonic ERZV10D680 Surge Absorber Varistor Specifications:
- Maximum Voltage: 680V
- Rated Voltage: 680V
- Maximum Clamping Voltage: 1120V
- Peak Current: 3500A (8/20μs waveform)
- Allowable Voltage: 1120V DC
- Energy Absorption Capacity: 850J
- Capacitance: 8.2pF
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +125°C
- Dimensions (mm): Dmax 12.5, Tmax 15.5, W+1.0 7.5, Hmax 19, L+1.0 49
- Material: Non-flammable resin encapsulation
- Standards: RoHS Compliant, UL1449, VDE IEC 61051-1, -2, CSA C22.2 No.269.5
- Application: Surge suppression in communication, consumer, and industrial electronics
Buy the Buy Panasonic Surge Absorber Part Number ERZV10D680 Online
Enhance your electronic circuit protection with the Panasonic ERZV10D680 surge absorber varistor. Featuring a maximum voltage of 680V and surge current capacity of 135A, this ROHS compliant component is ideal for suppressing transient overvoltages in communication and consumer electronics. Compact and reliable, it offers excellent energy absorption, low capacitance of 8.2pF, and operates effectively across a wide temperature range. Purchase online today for robust surge protection in your critical electronic devices.
Get Panasonic ERZV10D680 today—built for precision and long-lasting durability in surge protection applications.
Frequently Asked Questions
Where can I buy Panasonic ERZV10D680?
You can click on the BUY or RFQ button to purchase ERZV10D680 from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part ERZV10D680?
You can download the ERZV10D680 datasheet or visit the Panasonic website for support.
Who is the manufacturer of ERZV10D680?
Panasonic
