Panasonic SFY2DC12V Safety Relay
This safety relay features a 12 V DC coil voltage with contact configurations including two normally open and two normally closed DPST contacts. Designed for PCB mounting, it supports a current load of up to 6 amps, providing reliable safety switching functions. Equipped with forcibly guided contacts, it complies with EN 50205, Type A, enabling contact welding detection and safety circuit construction. Its compact design measures 33 x 28.6 x 14.5 mm, with reinforced insulation, making it suitable for machine safety, emergency stop systems, and automation applications, ensuring enhanced safety and durability in industrial environments.
Panasonic SFY2DC12V Safety Relay Specifications:
- Contact arrangement: 2 Form A 2 Form B
- Coil Voltage: 12V DC
- Contact Material: Gold-flashed AgNi alloy
- Contact Resistance (Initial): Max. 100 mΩ
- Nominal Switching Capacity: 6A 250V AC, 6A 30V DC
- Max Switching Power: 1500VA, 180W
- Insulation Resistance (Initial): Min. 1,000 MΩ at 500V DC
- Breakdown Voltage: Between open contacts 1500 Vrms, contacts and coil 2500 Vrms
- Operating Time (at 20°C): Max. 20ms, Release Time: Max. 10ms
- Shock Resistance: Min. 200 m/s²
- Vibration Resistance: 10 to 55 Hz at double amplitude 1.5 mm
- Degree of Protection: RTI
- Ambient Temperature: -40°C to +70°C
- Coil Power: 670 mW
- Dimensions: 33 x 28.6 x 14.5 mm
- RoHS compliant
Buy the Buy Panasonic Safety Relay Part Number SFY2DC12V Online
Discover the reliable Panasonic Safety Relay with 12V DC coil voltage supporting up to 6A current load. Compact and PCB mountable, it features forcibly guided contacts for enhanced safety, compliance with EN 50205, and suitable for emergency stop systems, machine safety, and automation projects. Designed for durability and safety compliance, this relay ensures dependable operation in rigorous industrial environments. Order online now to secure a high-quality, safety-certified relay that guarantees long-term performance and safety in your automation system.
Get Panasonic SFY2DC12V today—built for safety, precision, and long-lasting durability in industrial automation.
Frequently Asked Questions
Where can I buy Panasonic SFY2DC12V?
You can click on the BUY or RFQ button to purchase SFY2DC12V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part SFY2DC12V?
You can download the SFY2DC12V datasheet or visit the Panasonic website for support.
Who is the manufacturer of SFY2DC12V?
Panasonic
