Panasonic T115ASULF Control Switch
The T115 series switch is a versatile control component available in toggle, rocker, and push-button types, including sealed and wire lead options. Designed for industrial applications, these switches feature IP67 waterproof protection on the front panel and various sealing levels inside. Rated at 10 A for push-button types and 15 A for toggle and rocker types, they support resistive, inductive, lamp, and motor loads with a life expectancy of up to 3 million operations. Easy to install with optional accessories and capable of operating in temperatures from -25°C to +85°C.
Panasonic T115ASULF Control Switch Specifications:
- Contact Rating: Resistive load 15A 250V, Inductive load 15A 250V with Power factor 0.6, Lamp load 400W 100V, 800W 200V, Motor load 750W 250V
- Protection Grade: IP67 front panel, IP40/IP60/IP67 inside panel depending on type
- Actuator Life Expectancy: Min. 3x10^6 operations (standard, panel-sealed, terminal-sealed), Min. 1.5x10^6 (wire lead type)
- Dielectric Strength: 1500 Vrms at detection current of 10mA
- Insulation Resistance: Min. 100 MΩ at 500 V DC
- Vibration Resistance: 10-55 Hz at 1.5 mm double amplitude
- Operating Temperature: -25°C to +85°C
- Material: AgZn0 alloy contacts, rubber-sealed body with optional rubber caps, waterproof and dustproof
- Mounting Dimensions: 12.5 mm panel cutout, panel thickness max. 4.5 mm, mounting accessories include hex nuts, lock washers, keying washers
- Load and Switching: Mechanical life min. 3x10^6 cycles for standard, up to 3x10^7 cycles with proper use
- Compatibility: Suitable for control panels with environmental sealing requirements, robust against dust, water, oil, and gases
Buy the Panasonic Series T-15 Toggle Switch: T115ASULF
Order the Panasonic T115ASULF control switch online today for reliable operation in demanding environments. This waterproof toggle switch features IP67 sealing, supporting resistive, inductive, lamp, and motor loads. Designed for easy installation with versatile mounting accessories, it boasts a lifecycle of over 3 million operations. Suitable for industrial control panels exposed to water, dust, and gases, the switch performs reliably from -25°C to +85°C. Enhance your equipment’s durability by purchasing this high-quality, sealed control component online now.
Get Panasonic T115ASULF waterproof toggle switch today—built for rugged control and long-lasting durability in harsh environments.
Frequently Asked Questions
Where can I buy Panasonic T115ASULF?
You can click on the BUY or RFQ button to purchase T115ASULF from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part T115ASULF?
You can download the T115ASULF datasheet or visit the Panasonic website for support.
Who is the manufacturer of T115ASULF?
Panasonic
