Panasonic TQ224V signal relay
This is a signal relay with a 24 V DC coil voltage. It features a double pole double throw (DPDT) contact configuration, capable of handling up to 1 Amp of current. The relay is designed for PCB mounting and operates with a single side stable switching function.
Panasonic TQ224V signal relay Specifications:
- Contact arrangement: Double pole double throw (DPDT)
- Coil voltage: 24 V DC
- Maximum current: 1 A
- Mounting type: PCB
- Operating function: Single side stable
- Contact material: Gold-clad silver
- Switching capacity: 30W / 62.5VA
- Insulation resistance: Min. 1,000 MΩ at 500 V DC
- Initial contact resistance: Max. 720 mΩ
- Surge voltage withstand: 1500 V
- Operating time: Max. 3 ms
- Temperature rise: Max. 50°C at 20°C ambient
- Shock resistance: Min. 490 ms (50G), Min. 980 ms (100G)
- Vibration resistance: Functional at 3 mm amplitude, 10 to 55 Hz
- Ambient temperature: -40°C to +70°C
- Weight: approximately 20 grams
Buy the Panasonic TQ224V – Reliable Signal Relay for Industrial Applications
Enhance your control systems with the Panasonic TQ224V signal relay, featuring 24 V DC coil and DPDT contacts. Perfect for industrial automation, it offers reliable switching up to 1 Amp, with PCB mounting for easy integration. Its stable switching function and robust construction ensure long-lasting performance in demanding environments. Quickly purchase online to improve your automation projects with a proven, high-quality relay trusted by industries worldwide.
Buy Panasonic TQ224V now and experience unmatched reliability and performance for your industrial control needs.
Frequently Asked Questions
Where can I buy Panasonic TQ224V?
You can click on the BUY or RFQ button to purchase TQ224V from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part TQ224V?
You can download the TQ224V datasheet or visit the Panasonic website for support.
Who is the manufacturer of TQ224V?
Panasonic
