Panasonic TX2SA48VZ Signal Relay
This signal relay features a 9 V DC coil voltage, a double pole double throw contact configuration, and a current rating of 2 amps. Designed for surface-mount (SMD) mounting, it operates as a single side stable relay, suitable for various electronic switching applications with high dielectric strength and surge resistance, making it ideal for control and automation systems requiring reliable performance and compact size.
Panasonic TX2SA48VZ Signal Relay Specifications:
- Arrangement: 2 Form C
- Contact Resistance: Max. 100 mΩ (by voltage drop 6 VDC 1A)
- Contact Material: Ag+Au plating
- Nominal Switching Capacity: 2A 30V DC, 0.5A 125VAC
- Max Switching Power: 60 W, 60 VA
- Max Switching Voltage: 220V DC, 250V AC
- Max Switching Current: 7.5A
- Insulation Resistance: Min. 7,000 MΩ at 500V DC
- Breakdown Voltage: 2,000 Vrms contact-coil, 4,000 Vrms open contacts
- Surge Breakdown Voltage: 2,500 V between contact and coil
- Operate Time: Max. 4 ms
- Release Time: Max. 4 ms
- Shock Resistance: Functional 750 m/s², Destructive 1,000 m/s²
- Vibration Resistance: Functional 10-55 Hz at 3.3 mm amplitude, Destructive 10-55 Hz at 5 mm amplitude
- Ambient Temperature: -40°C to +70°C
- Unit Weight: Approx. 2.9 g
Buy the Buy Panasonic Signal Relay Part Number TX2SA48VZ Online
Purchase the Panasonic TX2SA48VZ surface-mount signal relay online today. With a 9V DC coil, 2A contact capacity, and high surge resistance, this relay ensures reliable performance in automation, control, and electronic switching applications. Its compact size and DPDT contact configuration make it ideal for space-constrained designs. Utilize this durable relay for dependable operation in various industrial and commercial systems. Buy now to ensure your projects benefit from Panasonic's quality and precision.
Get Panasonic TX2SA48VZ today—built for reliable switching with high surge resistance and compact design for electronic control.
Frequently Asked Questions
Where can I buy Panasonic TX2SA48VZ?
You can click on the BUY or RFQ button to purchase TX2SA48VZ from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part TX2SA48VZ?
You can download the TX2SA48VZ datasheet or visit the Panasonic website for support.
Who is the manufacturer of TX2SA48VZ?
Panasonic
