Panasonic TX2SAL224VZ Signal Relay
This signal relay features a 6 VDC coil voltage with a 2C DPDT contact configuration, capable of switching up to 2 amps. It has a high breakdown voltage of 2,000 V between contact and coil, and 1,000 V between open contacts, ensuring reliability. The relay's sealed construction offers automatic washing and robust resistance to vibration and shock. Designed for surface-mount applications, it includes 2-coil latching options for enhanced switching stability, making it ideal for industrial control, automation, and high-capacity switching tasks.
Panasonic TX2SAL224VZ Signal Relay Specifications:
- Arrangement: 2 Form C (DPDT)
- Contact Resistance: Max. 100 mΩ at 6 VDC 1A
- Contact Material: Ag+Au plating
- Nominal Switching Capacity: 2A 30V DC, 0.5A 125VAC
- Max. Switching Power: 60 W, 60 VA
- Max. Switching Voltage: 220V DC, 250V AC
- Max. Switching Current: 7.5 A
- Insulation Resistance: Min. 7,000 MΩ at 500V DC
- Initial Breakdown Voltage (contact to coil): 2,000 Vrms for 1 min
- Between open contacts: 4,000 Vrms for 1 min
- Between contact sets: 7,000 Vrms for 1 min
- Surge Breakdown Voltage (contact and coil): 2,500 V between contact and coil
- Operate Time: Max. 4 ms at 20°C
- Release Time: Max. 4 ms at 20°C
- Shock Resistance: Functional Min. 750 m/s²; Destructive Min. 1,000 m/s²
- Vibration Resistance: Functional 10-55Hz at 3.3 mm; Destructive 10-55Hz at 5 mm
- Operating Temperature: -40°C to +85°C
- Weight: Approx. 2.0 g
- Mounting Type: Surface-mount (SMD)
Buy the Panasonic Series TX Signal Relay: TX2SAL224VZ
Experience reliable switching with the Panasonic TX2SAL224VZ signal relay. Designed for surface-mount applications, it features a 6VDC coil voltage, 2A contact capacity, and high breakdown voltage for safety. Suitable for industrial automation, control panels, and high-capacity switching, this latching relay offers quick response times and robust construction to withstand vibration and shock. Purchase online today for superior performance, durable operation, and seamless integration into your control systems, ensuring operational reliability and efficiency.
Get Panasonic TX2SAL224VZ today—built for precision and long-lasting durability in automation and control systems.
Frequently Asked Questions
Where can I buy Panasonic TX2SAL224VZ?
You can click on the BUY or RFQ button to purchase TX2SAL224VZ from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part TX2SAL224VZ?
You can download the TX2SAL224VZ datasheet or visit the Panasonic website for support.
Who is the manufacturer of TX2SAL224VZ?
Panasonic
