Panasonic TXS2SA24VZ Signal Relay
This signal relay features a 24 V DC coil voltage with a double pole double throw (DPDT) contact configuration. It supports a current of 1 Amp and is designed for surface-mount (SMD) mounting. The relay operates in a single-side stable mode, making it suitable for various electronic switching applications. It offers high sensitivity of 70 mW (24 V DC), outstanding surge resistance, and reliable contact characteristics with initial resistance below 100 mΩ. Ideal for automation, measurement, security, and communication systems, ensuring durability and precise operation.
Panasonic TXS2SA24VZ Signal Relay Specifications:
- Coil Voltage: 24 V DC
- Contact Configuration: 2 Form C (DPDT)
- Contact Resistance: Max. 100 mΩ
- Contact Material: AgPd+Au clad
- Nominal Switching Capacity: 1A at 30V DC resistive load
- Operate Time: Max. 5 ms
- Release Time: Max. 5 ms
- Max. Switching Voltage: 110V DC
- Ambient Temperature Range: -40°C to +70°C
- Humidity: 5 to 85% RH
- Mechanical Life: Min. 1 million operations
- Electrical Life: Min. 100,000 operations at rated load
- Coil Power Consumption: 70 mW
- Dimensions: Refer to datasheet's mounting diagram
- Weight: Approx. 2 g
- Surge Resistance: Between open contacts 1,500V 10x160,1s; contacts and coil 2,500V 2x10us
- RoHS Directive Compatibility: Yes
Buy the Panasonic TXS2SA24VZ – Reliable DPDT Signal Relay for Industrial Applications
Purchase the Panasonic TXS2SA24VZ signal relay online today for your electronic switching needs. Its 24V DC coil, DPDT configuration, and 1A capacity provide reliable, precise switching. Designed for surface-mount installation, it features high sensitivity, surge resistance, and durable contact materials, making it ideal for automation, measurement, security, and communication systems. Enhance your project’s performance with this compact, robust relay built to withstand demanding industrial environments. Order now for quick, convenient online delivery of dependable quality.
Get Panasonic TXS2SA24VZ today—built for precision and long-lasting durability in industrial and automation systems.
Frequently Asked Questions
Where can I buy Panasonic TXS2SA24VZ?
You can click on the BUY or RFQ button to purchase TXS2SA24VZ from an authorized Panasonic distributor.
How do I troubleshoot issues or seek technical support for part TXS2SA24VZ?
You can download the TXS2SA24VZ datasheet or visit the Panasonic website for support.
Who is the manufacturer of TXS2SA24VZ?
Panasonic
