Panduit CJ6X88TGVL 45 Degree Angled Wire Cap
Panduit's 45° angled wire caps offer a solution for improved cable routing in tight spaces when used with compatible Mini-Com UTP jack modules. These caps terminate 4-pair cable, maintain cable pair geometry, and eliminate conductor untwist. They are color-coded for performance category designation and include a universal label for T568B wiring schemes. The angled design allows for a 55% reduction in cable routing depth compared to straight exit caps, making them ideal for modular furniture, raceways, and wall outlets. They support PoE and are UL rated, ensuring reliable performance in various applications.
Panduit CJ6X88TGVL 45 Degree Angled Wire Cap Specifications:
- Channel and component performance: Exceeds ANSI/TIA-568-C.2 and ISO 11801 standards
- IEC compliance: Meets IEC 60603-7
- RoHS compliance: Compliant
- PoE compliance: Supports 2500 connection cycles with IEEE 802.3af / 802.3at and 802.3bt
- UL rated: UL 1863 and UL 2043
- Operating temperature: -10°C to 65°C (14°F to 149°F)
- Conductor termination range: Compatible with 22 – 26 AWG solid or stranded cable
- Depth reduction provided: Allows 55% reduction in cable routing depth
- Angled cable exit: Maintains proper bend radius
- Reversible design: Can be inserted in either direction
- Wide compatibility: Compatible with Panduit’s Mini-Com UTP jacks
- Uses enhanced Giga-TX Technology: Optimizes performance and reduces installation time
- Consistent termination design: Ensures minimal learning curve
