Panduit LCDX614BL Two-Hole Copper Lug Connector
The PANDUIT LCDX6-14B-L is a robust copper lug connector suitable for a variety of industrial applications involving stranded copper wire. Constructed from high-conductivity seamless copper tubing and finished with electro-tin plating, this connector ensures reliable electrical connections. It is designed to accommodate Class B & C stranded copper wire and is UL listed for use in applications up to 35kv. The connector's color-coded barrel (blue) and markings provide easy identification, while the wire inspection window allows for visual confirmation of secure connections. Panduit die index P24 is recommended for optimal crimping.
Panduit LCDX614BL Two-Hole Copper Lug Connector Specifications:
- Material: High Conductivity Seamless Copper Tube
- Plating: Electro-Tin
- Wire Type: Stranded Copper: Class B & C, 37 R Ref
- Wire Strip Length: 9/16 in
- UL Listed Wire: Yes, for applications up to 35kv
- Connector Voltage: Consult manufacturer instructions
- UL Temperature Rating: 90°C
- C.S.A Certified: Yes
- Panduit Color Code: BLUE
- Panduit Die Index No: P24
- Alternate Die Index No: 224.01, 314.01
- Wire Inspection Window: Yes
Buy the LCDX6-14B-L PANDUIT Two-Hole Copper Lug Connector | myMectronic
Securely purchase the PANDUIT LCDX6-14B-L copper lug connector online today.
Buy Now
Frequently Asked Questions
Where can I buy Panduit LCDX614BL?
You can click on the BUY or RFQ button to purchase LCDX614BL from an authorized Panduit distributor.
How do I troubleshoot issues or seek technical support for part LCDX614BL?
You can download the LCDX614BL datasheet or visit the Panduit website for support.
Who is the manufacturer of LCDX614BL?
Panduit
