Phoenix Contact 1017505 PCB Terminal Block
This PCB terminal block is designed for board connections with a nominal current of 32 A and a rated voltage of 400 V (III/2). It features a 2.5 mm² conductor cross-section, a pitch of 5.08 mm, and four positions. The connection method utilizes push-in spring terminals and supports wave soldering. The conductor-to-PCB connection orientation is at 0°, with a linear double pin layout. The solder pins measure 3.5 mm in length, and the component comes in a green color. It complies with UL 94V-0 flammability standard and is suitable for industrial automation connections.
Phoenix Contact 1017505 PCB Terminal Block Specifications:
- Nominal current: 32 A
- Rated voltage: 400 V (III/2)
- Conductor cross section: 2.5 mm²
- Number of positions: 4
- Number of rows: 1
- Pitch: 5.08 mm
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Conductor connection: Open terminal point, solid 0.2 mm² ... 4 mm² or flexible 0.75 mm² ... 4 mm²
- Pin layout: Linear double pinning
- Solder pin length: 3.5 mm
- Material: Copper alloy, tin-plated
- Flammability rating: UL 94V-0
- Operating temperature: -40°C ... 105°C
- Compliance: IEC, UL, VDE, EAC, cULus recognized
Buy the Phoenix Contact Series TDPT PCB Terminal Block: 1017505
Order the Phoenix Contact TDPT 1017505 PCB terminal block online today for secure and reliable board connections. With a current capacity of 32 A and rated voltage of 400 V, it features push-in spring connection technology for fast assembly without tools. Its wave soldering compatibility and 5.08 mm pitch enable efficient manufacturing and maintenance. Made of high-quality copper alloy with tin-plated surfaces, it ensures excellent electrical contact stability. Perfect for industrial automation projects, it meets global safety standards, providing long-term durability and efficient performance for your electrical systems.
Buy Phoenix Contact TDPT 1017505 now and experience unmatched reliability and performance in your PCB connections.
Frequently Asked Questions
Where can I buy Phoenix Contact 1017505?
You can click on the BUY or RFQ button to purchase 1017505 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1017505?
You can download the 1017505 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1017505?
Phoenix Contact
