Phoenix Contact 1704858 Plug Connector
The Phoenix Contact PTSM 0,5/ 5-P-2,5 WH plug connector is a versatile component ideal for connecting wires to THR and SMD base strips. Its miniature design and 2.5mm pitch make it suitable for space-constrained applications. With a nominal current of 6A and rated voltage up to 160V, this connector provides reliable performance in industrial automation, control systems, and power distribution panels. The push-in spring connection ensures easy and secure termination of conductors, while the tin-plated contact surface enhances conductivity and corrosion resistance. Compliant with EN-VDE and UL standards, this plug connector offers a robust and dependable solution for a wide range of electrical applications.
Phoenix Contact 1704858 Plug Connector Specifications:
- Nominal current: 6 A
- Rated voltage (III/2): 160 V
- Number of positions: 5
- Pitch: 2.5 mm
- Connection method: Push-in spring connection
- Color: white
- Contact surface: Tin
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 100 V
- Rated voltage (II/2): 320 V
- Nominal cross section: 0.5 mm²
- Maximum load current: 6 A
- Flammability rating according to UL 94: V0
- Stripping length: 6 mm
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 0.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 0.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 0.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 20
- Minimum AWG according to UL/CUL: 26
- Maximum AWG according to UL/CUL: 20
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 1.4 g
- Custom tariff number: 85369010
- Country of origin: Poland
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440402
- eCl@ss 9.0: 27440402
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002637
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
Buy the 1704858 PHOENIX CONTACT Plug Connector | myMectronic
Purchase the Phoenix Contact 1704858 Plug Connector securely online for reliable industrial connections.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact 1704858?
You can click on the BUY or RFQ button to purchase 1704858 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1704858?
You can download the 1704858 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1704858?
Phoenix Contact
