Phoenix Contact 1714278 Plug Connector, 2 Positions
The Phoenix Contact GMSTB 2,5 HCV/ 2-ST-7,62 plug connector is designed for reliable and versatile electrical connections. Its well-known connection principle allows for worldwide use, while the low temperature rise ensures efficient heat dissipation. The integrated double steel spring provides added safety against temperature and power fluctuations. This connector is suitable for a wide range of industrial applications where secure and dependable connections are essential, and it is UL approved for compact dimensions.
Phoenix Contact 1714278 Plug Connector, 2 Positions Specifications:
- Nominal current: 16 A
- Rated voltage (III/2): 1000 V
- Number of positions: 2
- Pitch: 7.62 mm
- Connection method: Screw connection
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 4.47 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Width: 15.02 mm
- Dimension a: 7.62 mm
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (II/2): 6 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (II/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 8 mm
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
