Phoenix Contact 1714281 Plug Connector, 3 Positions
The Phoenix Contact 1714281 plug connector is a versatile component designed for use in a variety of industrial applications. Its compact design and 7.62mm pitch make it ideal for space-constrained environments. The screw connection with tension sleeve provides a secure and reliable connection, while the double steel spring enhances safety during temperature and power fluctuations. With a nominal current of 16A and a rated voltage of 1000V, this connector is suitable for power distribution, control systems, and automation equipment. It is commonly used in machinery, industrial automation, and renewable energy systems.
Phoenix Contact 1714281 Plug Connector, 3 Positions Specifications:
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 6.67 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Pitch: 7.62 mm
- Dimension a: 15.24 mm
- Range of articles: GMSTB 2,5 HCV/..-ST
- Insulating material group: I
- Rated surge voltage (III/3): 8 kV
- Rated surge voltage (III/2): 8 kV
- Rated surge voltage (II/2): 8 kV
- Rated voltage (III/3): 1000 V
- Rated voltage (III/2): 1000 V
- Connection in acc. with standard: EN-VDE
- Nominal current IN: 16 A
- Nominal cross section: 2.5 mm²
- Maximum load current: 16 A
- Insulating material: PA
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A3
- Stripping length: 8 mm
- Number of positions: 3
- Screw thread: M3
- Tightening torque, min: 0.5 Nm
- Tightening torque max: 0.6 Nm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 2.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- 2 conductors with same cross section, solid min.: 0.2 mm²
- 2 conductors with same cross section, solid max.: 1 mm²
- 2 conductors with same cross section, stranded min.: 0.2 mm²
- 2 conductors with same cross section, stranded max.: 1.5 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min.: 0.25 mm²
- 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max.: 1 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min.: 0.5 mm²
- 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max.: 1 mm²
- Minimum AWG according to UL/CUL: 30
- Maximum AWG according to UL/CUL: 12
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27260701
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440309
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002638
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
