Phoenix Contact 1768923 PCB Connector
This PCB connector is designed for reliable electrical connections in industrial and electronic projects. It supports a nominal current of 8 A and a rated voltage of 160 V category III/2, featuring a 3-position layout and a pitch of 3.81 mm. The screw connection with tension sleeve ensures secure mounting, and the green color indicates its standard application. Tin-plated contacts provide corrosion resistance and durability, making it suitable for various PCB applications requiring high performance and ease of installation in industrial environments.
Phoenix Contact 1768923 PCB Connector Specifications:
- Nominal current: 8 A
- Rated voltage: 160 V (category III/2)
- Number of positions: 3
- Pitch: 3.81 mm
- Connection method: Screw connection with tension sleeve
- Color: Green
- Contact surface: Tin-plated
- Cross-section: 1.5 mm²
- Standards: EN-VDE compliant
- Nominal voltage (additional): 160 V
- Connection range: 0.2-1.5 mm² (AWG 30-14)
- Approvals: VDE, IEC, UL, EAC
- Environmental compliance: China RoHS
- Material: Metal with tin plating
- Dimensions: Width 12.22 mm
- Min. conductor size: 0.2 mm²
- Max. conductor size: 1.5 mm²
Buy the Phoenix Contact 1768923 – Reliable PCB Connector for Industrial Applications
Enhance your electronic and industrial assemblies with the PCB connector supporting 8 A current and 160 V voltage, featuring a 3-position screw terminal design in green. This high-quality connector with tin-plated contacts ensures corrosion resistance and reliable performance. Its compact size, standard dimensions, and compliance with international standards make it ideal for PCB applications requiring secure, easy-to-install connections. Purchase online now and enjoy fast delivery, trusted quality, and seamless integration into your projects, securing reliable electrical connections in demanding environments.
Order your Phoenix Contact Series1768923 PCB connector today and ensure secure, durable connections for your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact 1768923?
You can click on the BUY or RFQ button to purchase 1768923 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1768923?
You can download the 1768923 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1768923?
Phoenix Contact
