Phoenix Contact 1772621 PCB Connector 3-Position
The Phoenix Contact TFMC 1,5/ 3-ST-3,5 is a versatile printed-circuit board connector designed for efficient and reliable connections. Its push-in spring-cage connection ensures fast and easy conductor termination, while the compact front TWIN connection minimizes space requirements. This connector is ideal for applications requiring signal distribution of up to 8A directly on the device. The integrated touch connection allows for convenient voltage testing using a standard test pin. It is commonly used in industrial control systems, automation equipment, and power distribution panels where reliable and space-saving connectivity is essential.
Phoenix Contact 1772621 PCB Connector 3-Position Specifications:
- Nominal current: 8 A
- Rated voltage (III/2): 160 V
- Number of positions: 3
- Pitch: 3.5 mm
- Connection method: Push-in spring connection
- Color: green
- Contact surface: Tin
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 1.0 g
- Custom tariff number: 85366990
- Country of origin: Poland
- Dimension a: 7 mm
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Range of articles: TFMC 1,5/..-ST
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 1.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 1.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 1.5 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 0.75 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 16
- Minimum AWG according to UL/CUL: 24
- Maximum AWG according to UL/CUL: 16
- Flammability rating according to UL 94: V0
- Internal cylindrical gage: A1
- Stripping length: 10 mm
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27260701
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440309
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002638
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
