Phoenix Contact 1777587 PCB Terminal Block
This green PCB terminal block offers reliable electrical connections with six positions, supporting a nominal current of 41 A and a voltage rating of 1000 V. Designed for PCB mounting with a 6.35 mm pitch and screw connection via tension sleeves, it is suitable for wave soldering processes. Features include a zigzag pin layout, conductor connection at 0°, and compatibility with various conductor sizes. The terminal block is ideal for industrial automation, control panels, and wiring applications requiring durable, high-current connections with UL and CE approvals.
Phoenix Contact 1777587 PCB Terminal Block Specifications:
- Dimensions: Length 15.85 mm, pitch 6.35 mm, solder pin length 5 mm
- Nominal Current: 41 A
- Rated Voltage: 1000 V (category III/2)
- Connection Method: Screw terminal with tension sleeve
- Number of Positions: 6
- Connection angle: 0°
- Color: Green
- Standards Compliance: UL, CE, VDE
- Soldering: Wave soldering suitable
- Approval: UL Recognized, cULus, EAC, CCA / SEV
Buy the Phoenix Contact Series MKDS PCB Terminal Block: 1777587
Order the Phoenix Contact PCB Terminal Block MKDS 1777587 online today to ensure secure and durable electrical connections. This green terminal block supports 41 A current and 1000 V voltage rating, ideal for industrial automation and control panels. Its screw connection with tension sleeves and wave soldering compatibility guarantee reliable wiring in demanding environments. Featuring six positions with a 6.35 mm pitch, it seamlessly integrates into various electrical systems. Purchase now and enhance your wiring projects with a trusted, UL-approved component designed for longevity and performance.
Buy Phoenix Contact MKDS 1777587 now and experience unmatched reliability and high-current capacity for industrial wiring applications.
