Phoenix Contact 1777600 PCB Terminal Block
This PCB terminal block features a nominal current rating of 41 A and a rated voltage of 1000 V (category III/2). It supports a nominal cross-section of 4 mm² and has a pitch of 6.35 mm. The terminal block includes 8 positions with a screw connection using tension sleeves for secure wiring, suitable for wave soldering mounting processes. Conductor to PCB connection is at a 0° orientation, with a green color indicator. It has a zigzag pin layout (W) and solder pins of 5 mm length.
Phoenix Contact 1777600 PCB Terminal Block Specifications:
- Nominal current: 41 A
- Rated voltage: 1000 V (III/2)
- Nominal cross section: 4 mm²
- Pitch: 6.35 mm
- Number of positions: 8
- Connection method: Screw connection with tension sleeve
- Mounting: Wave soldering
- Conductor connection direction: 0°
- Color: Green
- Pin layout: Zigzag pinning W
- Solder pin length: 5 mm
- Ambient temperature (operation): -5°C to +100°C
- Flammability: UL 94V-0
- Material data - contact: WEEE/RoHS compliant, free of whiskers
- Material data - housing: Flammability index GWFI according to EN 60695-2-12
- Hole diameter: 1.3 mm
- Dimensions for PCB design: Hole spacing 9 mm
Buy the Phoenix Contact 1777600 – Reliable PCB Terminal for Industrial Applications
Order the Phoenix Contact PCB Terminal Block 1777600 online and ensure reliable electrical connections in your industrial projects. Designed with a robust screw connection, wave soldering mounting, and a 6.35 mm pitch, it delivers secure wiring with a current capacity of 41 A and a voltage rating of 1000 V. The green-colored terminal has 8 positions, zigzag pin layout, and solder pins of 5 mm length for versatile application. Purchase now for efficient, durable, and compliant wiring solutions.
Get Phoenix Contact 1777600 today—built for precision and long-lasting durability in industrial wiring solutions.
Frequently Asked Questions
Where can I buy Phoenix Contact 1777600?
You can click on the BUY or RFQ button to purchase 1777600 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1777600?
You can download the 1777600 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1777600?
Phoenix Contact
