Phoenix Contact 1781030 PCB Connector
This PCB connector is designed for applications requiring a nominal current of 12 A and a rated voltage of 320 V. It features 7 positions with a pitch of 5.08 mm, and uses a screw connection with tension sleeve for secure wiring. The connector is green, with tin-coated contact surfaces for reliable electrical contact, and suited for PCB mounting in various industrial and electronic applications. Its robust design and compliance with standards make it suitable for secure connections in control and automation systems.
Phoenix Contact 1781030 PCB Connector Specifications:
- Rated current: 12 A
- Rated voltage: 320 V
- Number of positions: 7
- Pitch: 5.08 mm
- Connection method: Screw connection with tension sleeve
- Contact surface: Tin
- Color: Green
- Conductor cross section: 2.5 mm²
- Standards and approvals: CSA, VDE, IEC, cULus recognized
- Ambient temperature range: -55°C to +105°C
- Maximum load current: 12 A
- Rated surge voltage: 250 V
- Device compatibility: Suitable for PCB mounting and electronic control systems
Buy the Phoenix Contact Series Gnix PCB Connector: 1781030
Order the Phoenix Contact 1781030 PCB connector online today and ensure your electronic and industrial systems are built with reliable, high-quality connections. This connector offers easy screw termination, high current capacity of 12A, and a rated voltage of 320V, making it ideal for control panels, automation, and PCB applications. Its standardized design supports quick installation and secure contact, while the tin-coated surfaces ensure long-term electrical stability. Elevate your projects with a proven connector solution—available online for fast delivery and straightforward ordering.
Buy Phoenix Contact 1781030 now and experience unmatched reliability and performance in secure PCB connections.
Frequently Asked Questions
Where can I buy Phoenix Contact 1781030?
You can click on the BUY or RFQ button to purchase 1781030 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1781030?
You can download the 1781030 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1781030?
Phoenix Contact
