Phoenix Contact 1781108 PCB connector
This is a green PCB connector rated for a nominal current of 12 A and a rated voltage of 320 V (category III/2). It has a nominal cross section of 2.5 mm², 14 positions, and a pitch of 5.08 mm. The connection is made via a screw connection with a tension sleeve, and the contact surface is tin-plated. Designed for reliable use in electronic assembly, it complies with safety standards such as UL and CSA. The product features a compact design suitable for control and automation systems, ensuring secure and durable electrical connections across various industrial applications.
Phoenix Contact 1781108 PCB connector Specifications:
- Number of positions: 14
- Pitch: 5.08 mm
- Dimension a: 66.04 mm
- Connection: Screw terminal with tension sleeve
- Rated current: 12 A
- Rated voltage: 320 V (category III/2)
- Conductor cross section: 2.5 mm²
- Wire connection: Solid and stranded conductors, ferrules compatible
- Insulating material group: PA (Polyamide)
- Flammability class: UL 94V-0
- Contact material: Tin-plated
- Tightening torque: Min 0.5 Nm, Max 0.6 Nm
- Approval: UL, CSA certified
- Dimensions: 66.04 mm length, 8.3 mm width, 2.54 mm height
Buy the Phoenix Contact 1781108 – Reliable PCB Connectors for Industrial Applications
Order the Phoenix Contact PCB connector now and enjoy fast delivery and secure online shopping. Designed for reliability, this 14-position connector with a 5.08 mm pitch and 2.5 mm² cross section is ideal for industrial automation, control panels, and electronic systems. Featuring a screw terminal with tension sleeve and UL/CSA certification, it ensures safe and durable connections. Add this high-quality connector to your inventory today and enhance the efficiency and safety of your electrical assemblies.
Get Phoenix Contact 1781108 today—built for precision and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy Phoenix Contact 1781108?
You can click on the BUY or RFQ button to purchase 1781108 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1781108?
You can download the 1781108 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1781108?
Phoenix Contact
