Phoenix Contact 1788538 Terminal Block
This is a dense, reliable plug-in terminal block designed for precise electrical connections in industrial setups. It supports a nominal current of 12 A and a rated voltage of 320 V, suitable for various automation and control systems. Featuring two positions with a 5.08 mm pitch, it ensures flexible wiring with screw connections and tension sleeves for secure fastening. Its green color and tin-plated contact surface enhance durability and corrosion resistance. Ideal for direct mounting on panels or device housings, this terminal block offers modularity, compliance with standards, and wide compatibility for automation projects.
Phoenix Contact 1788538 Terminal Block Specifications:
- Nominal current: 12 A
- Rated voltage: 320 V (CAT III/II)
- Number of positions: 2
- Pitch: 5.08 mm
- Connection method: Screw connection with tension sleeve
- Color: Green
- Contact surface: Tin-plated
- Mounting: Direct mounting onto panels or equipment
- Width: 21.48 mm
- Maximum conductor cross section: 2.5 mm²
- Standards: EN-VDE, UL, cUL Recognized, CSA, IECEE CB Scheme
- Approval: CSA, UL, VDE, cUL, EAC
- Nominal voltage UL: 250 V
- Nominal voltage IEC: 300 V
- Wire range: 0.2-2.5 mm² (AWG 30-12)
Buy the Buy Phoenix Contact Base Strip Part Number 1788538 Online
Purchase your Phoenix Contact terminal block 1788538 today online to benefit from high-quality, reliable electrical connections. Designed for industrial automation, this 2-position module features a 5.08 mm pitch, supporting up to 12 A current and rated for 320 V. Its screw connection with tension sleeves offers secure wiring, ensuring durability and compliance with industry standards. Ideal for direct mounting on panels or devices, this terminal block combines easy installation with long-lasting performance for all your electrical control needs.
Order your Phoenix Contact SeriesMVSTBU 2,5/ 2-GB-5,08 terminal block today and ensure secure, flexible electrical connections with industry-standard quality.
Frequently Asked Questions
Where can I buy Phoenix Contact 1788538?
You can click on the BUY or RFQ button to purchase 1788538 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1788538?
You can download the 1788538 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1788538?
Phoenix Contact
