Phoenix Contact 1788868 DIN rail connector
This DIN rail connector is designed for electrical applications, supporting a nominal current of 12 A and a rated voltage of 320 V (category III/2). It accommodates conductors with a cross section of 2.5 mm² and features 16 connection positions with a pitch of 5.08 mm. The connector uses a screw connection method with a tension sleeve for secure attachment. It is color-coded green, with a tin-plated contact surface for reliable conductivity, and is mounted onto a standard DIN rail. Ideal for control panels and industrial wiring, ensuring secure and efficient connections.
Phoenix Contact 1788868 DIN rail connector Specifications:
- Number of positions: 16
- Pitch: 5.08 mm
- Width: 27.2 mm
- Dimension a: 76.2 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Connection type: Screw connection with tension sleeve
- Insulating material: PA
- Color: Green
- Tightening torque, minimum: 0.5 Nm
- Tightening torque, maximum: 0.6 Nm
- Rated surge voltage: 4 kV
- Rated voltage in category III/2: 320 V
- Conductor cross section (solid): 2.5 mm²
- Conductor cross section (stranded): 2.5 mm²
- Rated voltage (UL): 300 V
- Rated current (UL): 10 A
- Wire range: 0.2 mm² to 2.5 mm²
- Material: PA
- Certifications: CSA, UL, CUL, GOST, VDE-PZI
Buy the Buy Phoenix Contact MSTBVK 2,5/16-G-5,08 Part Number 1788868 Online
Purchase the Phoenix Contact DIN rail connector online today for reliable industrial wiring. Designed for 12 A and 320 V applications, it features 16 positions with 2.5 mm² conductor capacity. Perfect for control panels, automation systems, and electrical installations, it ensures secure screw connections with a tension sleeve. Its green color coding aids quick identification, and mounted on standard DIN rails, it provides stable electrical contact with a tin-plated surface. Get this essential component now for efficient, safe, and durable connectivity.
Order your Phoenix Contact MSTBVK 2,5/16-G-5,08 today and secure dependable connections for your industrial electrical projects.
Frequently Asked Questions
Where can I buy Phoenix Contact 1788868?
You can click on the BUY or RFQ button to purchase 1788868 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1788868?
You can download the 1788868 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1788868?
Phoenix Contact
