Phoenix Contact 1790296 PCB Terminal Block
The PHOENIX CONTACT MFKDSP/ 3-5,08 PCB terminal block is a versatile component for connecting wires to printed circuit boards. It offers a 5.08mm pitch and a 3-position design, making it suitable for various applications. The block utilizes a push-in spring connection for easy and secure wire termination. With a nominal current of 12A and a nominal voltage of 320V, it's designed for reliable performance in industrial environments. Its green color and wave soldering mounting option enhance its functionality and ease of integration into PCB assemblies. Compliant with EN-VDE standards, this terminal block ensures safety and quality in electrical applications.
Phoenix Contact 1790296 PCB Terminal Block Specifications:
- Nominal current: 12 A
- Nominal voltage: 320 V
- Pitch: 5.08 mm
- Number of positions: 3
- Connection method: Push-in spring connection
- Mounting: Wave soldering
- Conductor/PCB connection direction: 45 °
- Color: green
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece: 3.61 g
- Custom tariff number: 85369010
- Country of origin: Poland
- Length: 16.2 mm
- Dimension a: 10.16 mm
- Constructional height: 13 mm
- Length of the solder pin: 3.3 mm
- Pin dimensions: 0,5 x 1 mm
- Pin spacing: 10.16 mm
- Hole diameter: 1.3 mm
- Range of articles: MFKDSP
- Insulating material group: I
- Rated surge voltage III/3: 4 kV
- Rated surge voltage III/2: 4 kV
- Rated surge voltage II/2: 4 kV
- Rated voltage III/3: 250 V
- Rated voltage III/2: 320 V
- Rated voltage II/2: 630 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 1 mm²
- Maximum load current: 12 A (with 1.5 mm² conductor cross section)
- Insulating material: PA
- Solder pin surface: Sn
- Flammability rating according to UL 94: V0
- Stripping length: 10 mm
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 1.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 1 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 0.75 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule with plastic sleeve max.: 0.75 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 16
