Phoenix Contact 1790548 PCB Connector 8 Position
The PHOENIX CONTACT DFMC 1,5/ 8-ST-3,5-LR is a robust and reliable printed-circuit board connector suitable for a wide range of industrial applications. Its combination with very flat DMC headers and ultra-flat design height of 13.3 mm make it ideal for space-constrained environments. The spring-cage connection ensures fast and secure conductor connections, while the lock & release levers provide a convenient release mechanism. It supports conductor cross sections up to 1.5 mm² and is rated for a nominal current of 8 A and a voltage of 160 V, making it suitable for demanding applications.
Phoenix Contact 1790548 PCB Connector 8 Position Specifications:
- Base Series: DFMC 1,5
- Nominal Current: 8 A
- Rated Voltage (III/2): 160 V
- Number of Positions: 8
- Pitch: 3.5 mm
- Connection Method: Spring-cage connection
- Color: Green
- Contact Surface: Tin
- Insulating Material Group: I
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Surge Voltage (III/2): 2.5 kV
- Rated Surge Voltage (II/2): 2.5 kV
- Rated Voltage (III/3): 160 V
- Rated Voltage (II/2): 250 V
- Connection Standard: EN-VDE
- Nominal Cross Section: 1.5 mm²
- Maximum Load Current: 8 A
- Insulating Material: PA
- Flammability Rating: V0
- Stripping Length: 10 mm
- Conductor Cross Section Solid Min: 0.2 mm²
- Conductor Cross Section Solid Max: 1.5 mm²
- Conductor Cross Section Flexible Min: 0.2 mm²
- Conductor Cross Section Flexible Max: 1.5 mm²
- Conductor Cross Section Flexible w/ Ferrule Min: 0.25 mm²
- Conductor Cross Section Flexible w/ Ferrule Max: 1.5 mm²
- Conductor Cross Section Flexible w/ Plastic Sleeve Min: 0.25 mm²
- Conductor Cross Section Flexible w/ Plastic Sleeve Max: 0.75 mm²
- Conductor Cross Section AWG Min: 24
- Conductor Cross Section AWG Max: 16
- Minimum AWG (UL/CUL): 16
- Maximum AWG (UL/CUL): 24
- Packing Unit: 1 pc
- Weight per Piece: 8.8 g
- Custom Tariff Number: 85366990
- Country of Origin: Germany
- Length: 27.75 mm
- Height: 13.25 mm
- Width: 35 mm
- Dimension a: 24.5 mm
