Phoenix Contact 2900371 Solid-State Relay Module
The PHOENIX CONTACT PLC-OPT-60DC/230AC/1 (2900371) is a solid-state relay module designed for integration into PLC systems. It offers a slim design for space-saving installation on DIN rails and utilizes a push-in connection for easy wiring. The module provides reliable switching capabilities with a nominal input voltage of 60 V DC and an output voltage range of 24-253 V AC, capable of handling up to 0.75 A continuous current. Its features include zero-voltage switching, polarity protection, and an integrated input circuit, making it suitable for a wide range of industrial automation and control applications. The module is also characterized by its efficient connection to system cabling and high switching power.
Phoenix Contact 2900371 Solid-State Relay Module Specifications:
- Packing unit: 1 pc
- GTIN: 4046356508827
- Weight per Piece (excluding packing): 31.270 g
- Custom tariff number: 85364190
- Country of origin: Germany
- Utilization restriction: EMC: class A product, see manufacturer’s declaration
- Width: 6.2 mm
- Height: 80 mm
- Depth: 94 mm
- Ambient temperature (operation): -25 °C ... 60 °C
- Ambient temperature (storage/transport): -25 °C ... 70 °C
- Nominal input voltage UN: 60 V DC
- Input voltage range in reference to UN: 0.8 ... 1.2
- Input voltage range: 48 V DC ... 72 V DC
- Switching threshold "0" signal in reference to UN: ≤ 0.3
- Switching threshold "1" signal in reference to UN: ≥ 0.8
- Typical input current at UN: 6 mA
- Typical response time: 10 ms (at UN)
- Typical turn-off time: 10 ms (at UN)
- Operating voltage display: Yellow LED
- Type of protection: Reverse polarity protection
- Protective circuit/component: Polarity protection diode
- Transmission frequency: 10 Hz
- Power dissipation for nominal condition: 0.36 W
- Output voltage range: 24 V AC ... 253 V AC
- Limiting continuous current: 0.75 A (see derating curve)
- Maximum inrush current: 30 A (10 ms)
- Min. load current: 10 mA
- Leakage current: < 1 mA (in off state)
- Max. load value: 4.5 A (2s)
- Voltage drop at max. limiting continuous current: < 1 V
- Output circuit: 2-wire, floating
- Test voltage input/output: 2.5 kV (50 Hz, 1 min.)
- Mounting position: any
- Connection name (Input side): Push-in connection
- Stripping length (Input side): 8 mm
- Conductor cross section solid (Input side): 0.14 mm² ... 2.5 mm²
- Conductor cross section flexible (Input side): 0.14 mm² ... 2.5 mm²
- Conductor cross section AWG (Input side): 26 ... 14
- Connection name (Output side): Push-in connection
- Stripping length (Output side): 8 mm
- Conductor cross section solid (Output side): 0.14 mm² ... 2.5 mm²
- Conductor cross section flexible (Output side): 0.14 mm² ... 2.5 mm²
- Conductor cross section AWG (Output side): 26 ... 14
- Connection in acc. with standard: CUL
- Standards/regulations: IEC 60664, IEC 60664A, DIN VDE 0110
- Insulation: Basic insulation
- Pollution degree: 2
- Overvoltage category: III
- Lead: 7439-92-1
- China RoHS: Environmentally Friendly Use Period = 50
