Phoenix Contact 2910361 Surge Protection Device
This surge protection device is designed for single-channel operation with a remote indicator contact, providing reliable protection for 240 V AC systems. Featuring optical and mechanical status indication for individual arresters, it ensures status visibility and easy maintenance. The device is suitable for use in environments requiring high surge suppression, complying with IEC 61643-11 standards. It offers a compact form factor, IP20 protection rating when all terminal points are used, and is UL, cUL, and cULus listed for safety and compliance in industrial electrical installations, making it ideal for various surge suppression applications.
Phoenix Contact 2910361 Surge Protection Device Specifications:
- Dimensions: length 96.8 mm, width 69.8 mm, height 17.6 mm
- Ambient temperature (operation): -40°C ... 80°C
- Ambient temperature (storage/transport): -40°C ... 80°C
- Protection degree: IP20 (when all terminal points are used)
- Max. backup fuse: 125 A (gG)
- Short-circuit current rating: 200 kA
- Tightening torque: 30 Ib-in.
- Standards: IEC 61643-11 2011
- UL, cUL, cULus Listed
- Altitude: < 2000 m (ams)
- Permissible humidity (operation): 5% ... 95%
- Shock: 25g (Half-sine / 11 ms / 3x X, Y, Z)
- Vibration: 5g (10 ... 500 Hz / 2.5h / X, Y, Z)
Buy the Phoenix Contact VAL-US-240/40/1+0-FM – Reliable Surge Protection Device for Industrial Applications
Secure your electrical systems with the Phoenix Contact surge protection device, rated for 240 V AC. Designed with remote indicator contact and optical status indication, it ensures real-time system monitoring. It complies with IEC standards, is UL and cUL listed, and features a compact IP20 design suitable for industrial environments. Easy to install with a maximum backup fuse of 125 A and a short-circuit current rating of 200 kA. Reliable and durable, this device offers advanced surge suppression for critical electrical applications.
Order your Phoenix Contact VAL-US-240/40/1+0-FM surge protection device today and ensure high-quality surge suppression for your industrial electrical systems.
Frequently Asked Questions
Where can I buy Phoenix Contact 2910361?
You can click on the BUY or RFQ button to purchase 2910361 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 2910361?
You can download the 2910361 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 2910361?
Phoenix Contact
