Phoenix Contact CDDC154PV35 PCB connector
The PCB direct plug CDDC 1.5/4-PV-3.5 offers a compact, vibration-resistant connection with SKEDD direct plug-in technology. Designed for PCB mounting, it supports an 8A current, 160V rated voltage, and features a green housing with tin-plated contacts. The connector enables flexible positioning, high packing density, and is suitable for PCBs with chemically tin-plated or HAL surfaces. It is ideal for efficient, space-saving electrical connections in automation and industrial applications, combining ease of installation with reliable performance and compliance with international standards.
Phoenix Contact CDDC154PV35 PCB connector Specifications:
- Number of positions: 4
- Pin layout: Linear pinning
- Pitch: 3.5 mm
- Connection method: Crimp connection
- Housing color: Green (6021)
- Housing material: PA
- Rated current: 8 A
- Rated voltage (III/2): 160 V
- Conductor cross section: 0.14 mm² ... 1.5 mm² (AWG 26-16)
- Contact surface: Tin
- Contact resistance: 1.5mΩ
- Insertion/withdrawal cycles: 25
- Mechanical strength: Insertion approx. 4N, withdrawal approx. 3N
- Minimum clearance: 1.5 mm
- Minimum creepage distance: 1.5 to 2 mm
- Temperature range (operation): -55°C to +105°C
- Ambient temperature (storage/transport): -40°C to 70°C
- Ambient temperature (assembly): -5°C to 100°C
- Locking: Self-locking flange
- Insulation material: PA
- Insulation group: I
- Flammability rating: UL 94 VO
- Glow wire flammability index: 850
- Glow wire ignition temp: 775°C
- Dimensions: Height: 16mm, Width and length vary
- Contact certifications: UL, VDE, IEC CB
- Standards compliance: IEC 61984, IEC 60512
- Environmental: IP20 degree of protection
Buy the Buy Phoenix Contact PCB Direct Plug Part Number CDDC154PV35 Online
Secure your industrial and automation projects with the high-quality Phoenix Contact PCB connector featuring SKEDD technology. This 4-pos, 8A rated connector with a 3.5mm pitch simplifies installation, guarantees vibration resistance, and allows flexible PCB positioning. Its compact, space-efficient design with tin-plated contacts ensures reliable electrical performance across a wide temperature range. Ideal for automation, control systems, and manufacturing, shop online now to enjoy quick delivery, professional support, and reliable, industry-grade connection solutions tailored to your project needs.
Order your Phoenix Contact Series CDDC 1.5/4-PV-3.5 PCB direct plug today and ensure reliable, space-saving connections for your industrial projects.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC154PV35?
You can click on the BUY or RFQ button to purchase CDDC154PV35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC154PV35?
You can download the CDDC154PV35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC154PV35?
Phoenix Contact
