Phoenix Contact CDDC156PV35 PCB connector
The PCB direct plug CDDC 1.5/6-PV-3.5 is a flexible, vibration-resistant connector suitable for PCB applications, featuring SKEDD direct plug-in technology for quick, tool-free insertion. It offers high packing density with 6 positions in a compact design, rated for 8 A and 160 V. Made from durable materials with tin-plated contacts, it ensures reliable connections and is compatible with various surface finishes. Ideal for industrial wiring, automation, and control systems requiring robust, cost-effective connections.
Phoenix Contact CDDC156PV35 PCB connector Specifications:
- Range of articles: CDDC 1.5/6-PV-3.5
- Pitch: 3.5 mm
- Number of positions: 6
- Nominal current: 8 A
- Rated voltage: 160 V
- Connection method: Crimp connection
- Flexible conductor cross section: 0.14 mm² ... 1.5 mm²
- Conductor AWG/kcmil: 26-16
- Housing color: Green (6021)
- Housing material: PA (Polyamide), Flammability rating UL 94 V-0
- Flammability rating: UL 94 V-0
- Insulation group: CTI 600 according to IEC 60112
- Glow wire flammability index: GWFI 850°C
- Glow wire ignition temperature: GWIT 775°C
- Dimensions: Length 13 mm, Width specified as per model
- Ambient temperature (storage/transport): -40°C ... 70°C
- Ambient temperature (assembly): -5°C ... 100°C
- Ambient temperature (operation): -55°C ... 105°C
- IP rating: IP20
Buy the Phoenix Contact Series CDDC PCB Direct Plug: CDDC 1.5/6-PV-3.5
Order the Phoenix Contact PCB connector with SKEDD direct plug-in technology today for your industrial wiring or automation projects. Featuring a 6-position design with 1.5 mm² conductors, rated for 8 A and 160 V, it ensures vibration resistance, high packing density, and reliable crimp connections. Made from durable PA material with tin-plated contacts, it is easy to install without tools. Perfect for control panels, automation systems, and manufacturing lines requiring robust, cost-effective, and space-saving connection solutions. Buy online now for fast delivery.
Get Phoenix Contact CDDC 1.5/6-PV-3.5 today—built for reliable, vibration-resistant PCB wiring with quick, tool-free insertion.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC156PV35?
You can click on the BUY or RFQ button to purchase CDDC156PV35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC156PV35?
You can download the CDDC156PV35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC156PV35?
Phoenix Contact
