Phoenix Contact CDDC157PV35 PCB Connector
The PCB direct plug CDDC 1.5/7-PV-3.5 offers a reliable, vibration-resistant connection with a compact design, supporting up to 8A and 160V rated voltage. Utilizing SKEDD direct plug-in technology, it features 7 positions with linear pinning and a 3.5mm pitch, suitable for PCB assembly. The green, tin-contact surface and robust insulating PA housing ensure high durability and safety. Compatible with various surface finishes, it offers high packing density, easy hand insertion, and is ideal for cost-effective large-scale applications in industrial automation and control systems.
Phoenix Contact CDDC157PV35 PCB Connector Specifications:
- Number of positions: 7
- Connection method: Crimp connection
- Mounting type: SKEDD - Direct plug-in technology
- Pin layout: Linear pinning
- Nominal current: 8A
- Rated voltage: 160V
- Conductor cross section: 0.14 mm² ... 1.5 mm²
- Housing color: Green (6021)
- Housing material: PA
- Flammability rating: UL 94 vo
- Surge voltage: 2.95 kV
- Temperature range (operation): -55°C to 105°C
- Dimensions: Length varies with model, pitch 3.5mm
- Protection class: IP20
- Standards: IEC 61984, IEC 60664-1, IEC 60512
- Approvals: cULus Recognized, VDE, CB Scheme
Buy the Phoenix Contact CDDC157PV35 – Reliable PCB Connector for Industrial Applications
Purchase the PCB direct plug CDDC 1.5/7-PV-3.5 online today to benefit from a Vibration-resistant and cost-effective connection solution. Designed for PCB assembly, it features 7 positions, supports up to 8A current with 160V rated voltage, and utilizes SKEDD direct plug-in technology for easy, vibration-proof insertion. Its green insulating housing, tin-plated contacts, and compact pitch of 3.5mm make it ideal for high-density industrial automation, control systems, and electronic projects. Secure your supply of reliable connectors for large-scale manufacturing needs now.
Get Phoenix Contact CDDC157PV35 today—built for precision, durability, and high-density PCB connections in industrial environments.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC157PV35?
You can click on the BUY or RFQ button to purchase CDDC157PV35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC157PV35?
You can download the CDDC157PV35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC157PV35?
Phoenix Contact
