Phoenix Contact CDDC253PV50 PCB Direct Connector
The CDDC 2.5/3-PV-5.0 is a PCB direct connector featuring SKEDD plug-in technology, designed for quick, vibration-resistant connections with a 3-position, 5 mm pitch. It supports a rated current of 12 A, rated voltage of 320 V, and accommodates conductor cross-sections from 0.14 mm² to 2.5 mm². The green housing with tin-plated contacts ensures reliable electrical performance and high packing density, suitable for various industrial applications. Its self-locking flange provides mechanical stability, making it ideal for compact, high-density electronic assemblies.
Phoenix Contact CDDC253PV50 PCB Direct Connector Specifications:
- Number of positions: 3
- Pitch: 5 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Conductor cross section: 0.14 mm² to 2.5 mm²
- Housing color: Green
- Housing material: PA
- Contact surface: Tin-plated
- Connection method: Crimp
- Mounting: SKEDD direct plug-in technology
- Pin layout: Linear
- Locking: Self-locking flange
- Number of levels: 2
- Number of connections: 6
- Rated surge voltage: IEC 60664-1:2007-04 minimum clearance 3mm, creepage distance 3.2mm
- Ambient temperature (operation): -55°C to 105°C
- Flammability rating: UL 94 vo
- Insulation material: PA, group 1, CTI 600
- Approvals: cULus Recognized, VDE, CB scheme
- Dimensions: Width and height approx. 13 mm, length 13 mm, pin spacing 5 mm
- Environmental: Storage temperature -40°C to 70°C, installation -5°C to 100°C
Buy the Buy Phoenix Contact CDDC 2.5/3-PV-5.0 Part Number CDDC253PV50 Online
Order the Phoenix Contact CDDC 2.5/3-PV-5.0 direct connector online today for high-density PCB applications. Featuring SKEDD plug-in technology, this versatile connector offers quick, vibration-resistant connections, simplifying assembly. Its green housing with tin-plated contacts ensures excellent electrical conductivity and durability. Suitable for conductor cross-sections from 0.14 mm² to 2.5 mm², it supports a rated current of 12 A at 320 V, making it ideal for industrial automation and control systems. Trust Phoenix Contact for reliable, easy-to-install PCB connections.
Get Phoenix Contact CDDC 2.5/3-PV-5.0 today—built for reliable PCB connections in industrial automation applications.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC253PV50?
You can click on the BUY or RFQ button to purchase CDDC253PV50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC253PV50?
You can download the CDDC253PV50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC253PV50?
Phoenix Contact
