Phoenix Contact CDDC257PV50 PCB Connector
The CDDC 2.5/7-PV-5.0 is a high-density, flexible PCB direct connector with SKEDD plug-in technology. It features 7 positions with a 5 mm pitch, rated for 12 A and 320 V, suitable for various industrial applications. The green housing is made from PA with UL 94 V-0 flammability rating and a CTI of 600. Designed for vibration-resistant, tool-free insertion, its linear pin layout along with double-row contacts facilitates reliable connections in compact spaces, ideal for large-scale installations requiring cost-effective and durable PCB connections.
Phoenix Contact CDDC257PV50 PCB Connector Specifications:
- Number of positions: 7
- Pitch: 5 mm
- Rated current: 12 A
- Rated voltage: 320 V
- Connection method: Crimp connection
- Housing color: Green
- Housing material: PA with UL 94 V-0 rating
- Insulating material group: I
- CTI: 600
- Flammability rating: UL 94 V-0
- Glow wire flammability index: GWFI 850
- Glow wire ignition temperature: GWIT 775°C
- Ambient temperature (storage/transport): -40°C to 70°C
- Ambient temperature (assembly): -5°C to 100°C
- Ambient temperature (operation): -55°C to 105°C
- Dimensions: Length 13 mm, Width 40.8 mm
- Pin layout: Linear pinning
- Mounting: SKEDD – Direct plug-in technology
- Minimum clearance: 3 mm
- Minimum creepage: 3 mm
- Conductor cross section: 0.14 mm² to 2.5 mm² (AWG 26-14)
- Approval: cULus Recognized, VDE, CB Scheme
- Compliance: IEC 61984, IEC 60512, IEC 60664-1
Buy the Phoenix Contact CDDC 2.5/7-PV-5.0 – Reliable PCB Connector for Industrial Applications
Purchase the Phoenix Contact PCB Connector today for reliable, vibration-resistant, and high-density connections on your PCB assemblies. Designed with SKEDD direct plug-in technology, it offers quick, tool-free insertion, reducing assembly time and costs. Rated for 12 A and 320 V, its durable housing and precise 5 mm pitch make it suitable for demanding industrial environments. Whether for large-scale manufacturing or automation projects, this connector ensures a secure, high-quality electrical connection in compact spaces, leading to reduced maintenance and enhanced system reliability.
Get Phoenix Contact CDDC 2.5/7-PV-5.0 today—built for precision, vibration resistance, and long-lasting durability in industrial PCB connections.
Frequently Asked Questions
Where can I buy Phoenix Contact CDDC257PV50?
You can click on the BUY or RFQ button to purchase CDDC257PV50 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part CDDC257PV50?
You can download the CDDC257PV50 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of CDDC257PV50?
Phoenix Contact
