Phoenix Contact DFKMSTB256G508 Base Strip Connector
The PHOENIX CONTACT DFK-MSTB 2,5/ 6-G-5,08 base strip connector provides a robust and versatile solution for connecting wires and components in various industrial applications. Its design allows for flexible connection methods, including solder and slip-on plug-in connections, catering to diverse assembly requirements. The connector's 5.08mm pitch and 6-position configuration make it suitable for a range of applications, from control panels to automation systems. It can be fixed in housing panels up to 6mm thick using M3 x 10 screws, ensuring secure and stable mounting. Compatible with MSTB and MSTBT plugs, this connector simplifies integration into existing systems and offers a reliable connection for power and signal transmission.
Phoenix Contact DFKMSTB256G508 Base Strip Connector Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 320 V
- Number of positions: 6
- Pitch: 5.08 mm
- Connection method: Solder/Slip-on connection
- Color: green
- Contact surface: Tin
- Mounting: Direct mounting
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 6.95 g
- Custom tariff number: 85366990
- Country of origin: Germany
- Dimension a: 25.4 mm
- Range of articles: DFK-MSTB 2,5/..-G
- Insulating material group: I
- Rated surge voltage (III/3): 4 kV
- Rated surge voltage (III/2): 4 kV
- Rated surge voltage (II/2): 4 kV
- Rated voltage (III/3): 320 V
- Rated voltage (II/2): 630 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Insulating material: PA
- Flammability rating according to UL 94: V2
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27141134
- eCl@ss 9.0: 27141134
- ETIM 3.0: EC001283
- ETIM 4.0: EC001283
- ETIM 5.0: EC001283
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
Buy the 0707280 PHOENIX CONTACT Base Strip Connector | myMectronic
Secure your PHOENIX CONTACT 0707280 Base Strip Connector with our reliable online procurement platform.
