Phoenix Contact DFMC156ST35 PCB Connector
The DFMC 1.5/6-ST-3.5 printed-circuit board connector offers a fast, tool-free push-in connection with stable contact force, ideal for tight installation spaces. It features six positions, a pitch of 3.5mm, and tin-plated contacts for reliable electrical connectivity. Suitable for a rated current of 8A and rated voltage of 160V, this green connector complies with EN-VDE standards and UL 94V-0 flammability rating. Its compact dimensions and user-friendly design make it suitable for automation, control systems, and industrial applications requiring robust and efficient PCB connections.
Phoenix Contact DFMC156ST35 PCB Connector Specifications:
- Number of positions: 6
- Connection method: Push-in spring connection
- Pitch: 3.5mm
- Rated current: 8A
- Rated voltage: 160V (III/2), 250V (Il/2)
- Contact surface: Tin-plated
- Insulating material: PA
- Flammability rating: UL 94V-0
- Dimensions: Length 22.65mm, Height 13.25mm, Width 21.8mm, Dimension a 17.5mm
- Stripping length: 10mm
- Conductor cross section solid/min: 0.2mm² (AWG 24), max: 1.5mm² (AWG 16)
- Conductor cross section flexible/min: 0.2mm², max: 1.5mm² (AWG 24-16)
- Maximum load current: 8A
- Standards: EN-VDE, UL 94V-0
- Certifications: VDE, cULus Recognized, EAC
Buy the Buy Phoenix Contact DFMC 1.5/6-ST-3.5 Part Number DFMC156ST35 Online
Secure your electronic projects with the Phoenix Contact PCB connector, designed for quick, tool-free push-in connection, sturdy contact force, and reliable performance. With six positions, a pitch of 3.5mm, and tin-plated contacts, it offers easy installation even in tight spaces. Perfect for automation, control systems, and industrial applications, this connector meets UL 94V-0 flammability standards and complies with EN-VDE safety regulations. Enhance your assembly process with a durable, high-quality PCB connection solution from Phoenix Contact.
Buy Phoenix Contact DFMC 1.5/6-ST-3.5 now and experience unmatched reliability and performance in PCB connections with easy push-in technology.
Frequently Asked Questions
Where can I buy Phoenix Contact DFMC156ST35?
You can click on the BUY or RFQ button to purchase DFMC156ST35 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFMC156ST35?
You can download the DFMC156ST35 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFMC156ST35?
Phoenix Contact
