Phoenix Contact FKCOR2512ST508 PCB Connector
The FKCOR 2.5/12-ST-5.08 from Phoenix Contact is a 12-pole female connector designed for printed circuit board (PCB) mounting with a 5.08mm pitch. Its unique conductor connection is orthogonal to the direction of operation, simplifying cabling for DIN rail-mounted devices. The connector features a quick, tool-free push-in connection with color-coded actuating lever for intuitive use, and has integrated testing options. It is compatible with the MSTB 2.5 range of connectors. Rated for surge voltages up to 4kV and voltages up to 250V (III/3), 320V (III/2), and 630V (II/2). The nominal current is 12A with a rated cross section of 2.5mm², and it supports conductor cross sections from 0.2mm² to 2.5mm² (24 AWG to 12 AWG). The stripping length is 10mm. Suitable for industrial applications.
Phoenix Contact FKCOR2512ST508 PCB Connector Specifications:
- Dimensions: Length 23.7mm, Width 60.83mm, Height 14.3mm
- Pitch: 5.08mm
- Rated Voltage: 320V (III/2), 250V (III/3), 630V (II/2)
- Rated Surge Voltage: 4kV
- Nominal Current: 12A
- Nominal Cross Section: 2.5mm²
- Conductor Cross Section (Solid/Flexible): 0.2mm² - 2.5mm² (24-12 AWG)
- Stripping Length: 10mm
- Connection Method: Push-in spring connection
- Number of Positions: 12
- Color: Green
- Contact Surface: Tin
- Standard Compliance: EN-VDE
- Weight per Piece: 15.9g
- Applicable Industry: Industrial automation and control systems
Buy the Phoenix Contact Series PCB Connector: FKCOR 2.5/12-ST-5.08
Purchase the Phoenix Contact FKCOR 2.5/12-ST-5.08 online today to ensure your industrial PCB wiring is fast, secure, and reliable. With its innovative push-in spring connection, this 12-pole connector allows for quick and tool-free installation, reducing downtime. Its orthogonal conductor connection simplifies cabling for DIN rail-mounted devices. Rated for 12A and 320V, it features a 5.08mm pitch, tin-plated contacts for durability, and compatibility with MSTB 2.5 series. Ideal for industrial automation, it guarantees long-lasting, safe connections in demanding environments.
Get Phoenix Contact FKCOR 2.5/12-ST-5.08 today—designed for reliable PCB connections with quick push-in terminals and surge voltage protection.
