Phoenix Contact FKCOR253ST508LR Printed Circuit Board Connector
The FKCOR 2.5/3-ST-5.08-LR from Phoenix Contact is a 5.08 mm pitch, 3-pin female printed circuit board connector. It features an automatic locking mechanism and an intuitive release lever in contrasting color for easy operation. The conductor connection is orthogonal to the direction of insertion, simplifying cabling of DIN-rail-mountable devices. It offers a quick and tool-free push-in spring connection with tin-plated contacts, and supports integrated testing options. The connector is rated for a surge voltage of 4 kV and a rated voltage of up to 630V, with a nominal current of 12A and supports conductor cross sections from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG). Suitable for industrial applications.
Phoenix Contact FKCOR253ST508LR Printed Circuit Board Connector Specifications:
- Pitch: 5.08 mm
- Number of positions: 6
- Rated voltage: up to 630V
- Rated surge voltage: 4 kV
- Nominal current: 12A
- Contact material: Tin-plated
- Connection method: Push-in spring connection
- Conductor cross section: 0.2 mm² to 2.5 mm² (AWG 24-12)
- Dimensions: Length 29.1 mm, Width 24.24 mm, Height 14.7 mm
- Flammability rating: UL 94 V-0
- Stripping length: 10 mm
- Material: Insulating material group not specified
- Standards: EN-VDE, UL
- Environmental compliance: China RoHS
Buy the Buy Phoenix Contact FKCOR 2.5/3-ST-5.08-LR Part Number FKCOR253ST508LR Online
Order the Phoenix Contact FKCOR 2.5/3-ST-5.08-LR printed circuit board connector online today. This 6-position connector features a 5.08 mm pitch, push-in spring connection for easy installation, and a robust design rated for 12A and up to 630V. Its orthogonal conductor connection simplifies cabling of DIN-rail-mounted devices. Equipped with an intuitive locking and release lever, it ensures secure, tool-free operation. Ideal for industrial applications requiring precise, reliable electrical connections that support various conductor sizes.
Get Phoenix Contact FKCOR 2.5/3-ST-5.08-LR today—built for quick and reliable PCB connections with tool-free push-in spring technology.
Frequently Asked Questions
Where can I buy Phoenix Contact FKCOR253ST508LR?
You can click on the BUY or RFQ button to purchase FKCOR253ST508LR from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part FKCOR253ST508LR?
You can download the FKCOR253ST508LR datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of FKCOR253ST508LR?
Phoenix Contact
